Cardiovascular Risk in Diabetes Mellitus: Cause and Effect

The clinical significance between DM and comorbid conditions is highlighted in the relationship between ACS and diabetes [1••]. The incidence of diabetes among ACS patients ranges from 15 to 35 %. It is also important to consider the number of ACS patients who may have undiagnosed diabetes and could, therefore, benefit from a broader approach to their ACS treatment regimen. Additionally, a subset of patients with diabetes have unrecognized renal insufficiency, a factor that may impact proper drug dosing and length of hospital stay. Finally, approximately 35 % of the US population is prediabetic [1••], which may further impact their overall CVD risk profile.

The concern about diabetes is not just related to acute care in the ED. Diabetes is a chronic disease with potentially serious consequences. Over time, diabetes results in damage and dysfunction in multiple organ systems. Vascular disease is a major cause of many of the sequelae of long-term disordered glucose metabolism. Both microvascular disease (retinopathy, nephropathy, and neuropathy), that is specific to diabetes, and macrovascular disease (involving the coronary, cerebral, and peripheral vascular supplies), that occurs with increased frequency in diabetes, contribute to the high morbidity and mortality rates associated with this disease [2•].

Atherosclerotic macrovascular disease occurs with increased frequency in diabetes, resulting in an increased incidence of myocardial infarction, stroke, claudication and gangrene of the lower extremities. Although macrovascular disease accounts for significant morbidity and mortality in both type 1 (T1D) and type 2 diabetes (T2D), the effects of large-vessel disease are particularly devastating in Type 2 DM and are responsible for approximately 75 % of diabetes-related deaths [2•, 3].

Diabetes is traditionally classified as type 1 or type 2. In the past, type 1 has also been termed “juvenile-onset” and “insulin-dependent,” and type 2 was referred to as “adult-onset” and “non-insulin-dependent” diabetes. As the pathophysiology of the disease has been better elaborated, treatment approaches have evolved, and the incidence of childhood obesity has increased, these distinctions are now not so clear. A better way to differentiate the two is by considering the amount and effectiveness of basal insulin in the individual patient’s system; patients who have a true insulin deficiency are type 1, and require insulin replacement therapy. Those who make insulin but either in insufficient amounts (as in many morbidly obese diabetic patients) or in the presence of reduced cellular insulin receptor activity are designated type 2 and may be treated with oral agents, supplemental insulin, behavioral and dietary changes, or all of these [2•].

Diabetes increases the risk of atherosclerosis in at least three ways: (1) the incidence of traditional risk factors, such as hypertension and hyperlipidemia, is increased among diabetics (50 and 30 % incidence at diagnosis, respectively); (2) diabetes itself is an independent risk factor for atherosclerosis; and (3) diabetes appears to synergize with other known exogenous risk factors (such as smoking and obesity) to increase atherosclerosis. The elimination of other risk factors, therefore, can greatly reduce the risk of atherosclerosis in diabetes [2•, 3].

To better understand the clinical implications of this, it will be useful to take a closer look at the pathophysiological relationship between elevated glucose levels and vascular disease.

Vasculitis is an important component of the diabetes syndrome. Components of the immune system are altered in obesity and T2D, with the most apparent changes occurring in adipose tissue, the liver, pancreatic islets, the vasculature, and circulating leukocytes. Inflammatory mechanisms in T2D may include local hypoxia, premature death of lipid cells, and metabolic stresses associated with insulin resistance. Metabolic stresses result in subsequent activation of stress-induced proinflammatory cytokines, which may be associated with the recruitment of inflammatory cells [4]. Circulating inflammatory cells and immune cells constitute an important part of an atheroma [5], and diabetes accelerates the process of atherosclerosis and, therefore, predisposes the patient to CVD.

Data indicate that high intracellular levels of glucose in cells that cannot down-regulate glucose entry result in microvascular damage via four distinct, diabetes-specific pathways: (1) increased polyol pathway flux, (2) increased formation of advanced glycation end-product, (3) activation of protein kinase C, and (4) increased hexosamine pathway flux.

More recent information suggests that increased flux through these four pathways is induced by a common factor: mitochondrial-derived reactive oxygen species, which are generated by increased flux of glucose through the tricarboxylic cycle. The end result of these changes in the microvasculature is an increase in protein accumulation in vessel walls, a loss of endothelial cells, and, ultimately, occlusion. Evidence suggests that all four of these pathways may actually be linked by a common mechanistic element: hyperglycemia-induced oxidative stress.

The common pathway between DM and coronary artery disease may be endothelial dysfunction. Lumsden and colleagues conducted a single visit study to examine whether endothelial function was normal following aggressive treatment of cardiovascular risk factors in 15 patients with T2D and a history of ACS [6]. At the end of the study, total and low-density lipoprotein cholesterol levels were well controlled. However, other risk factors, such as increased body mass index, increased systolic blood pressure, glucose, and triglyceride levels, and lower high-density lipoprotein levels were still present. Analysis of endothelial function using several different methods revealed that these patients with T2D exhibit residual cardiovascular risk factors despite being on standard clinical care. They continue to show evidence of endothelial dysfunction, which has been shown to be an independent predictor of cardiovascular events. Thus, providing optimal glycemic control may provide an additional benefit to patients with CVD through its impact on endothelial function [6].

With the inextricable relationship between DM and CVD in mind, it is clear that identification of diabetes in patients who also have CVD is essential for a smooth transition of care to the inpatient service. The treatment process can begin in the ED after the patient’s condition is known and can continue in an uninterrupted fashion by the hospitalist or cardiologist who manages these patients in the hospital. The initiation of aggressive secondary prevention measures while the patient is in the ED may not be common practice today; however, there appears to be an opportunity to start the patient on the proper course—perhaps at a “teachable moment” in the ED—as he or she is actually admitted to the hospital.

DM is an important consideration for both the emergency physician and the hospitalist because of the growing number of patients with this disease who become part of the ED and hospital population. The 2011 National Diabetes Fact Sheet states that approximately 25.8 million people have DM in the United States, which represents over 8 % of the population. Of those, 18.8 million carry a diagnosis but seven million remain undiagnosed. An additional 79 million people¹ have prediabetes. There were approximately 1.9 million new cases of diabetes diagnosed in people aged 20 years and older in 2010. The disease is relatively more common in African-Americans and Hispanics [7]. If diabetes was an isolated disease, these striking epidemiological figures would not seem as important. However, because DM is often associated with one or more comorbidities, DM is becoming one of the key factors driving hospitalization.

In 2007, diabetes was listed as the underlying cause on over 70,000 death certificates and was listed as a contributing factor on more than 160,000 death certificates: over 230,000 deaths in 1 year, and the number is growing. In addition to mortality risk, diabetes is associated with target organ damage in several different systems [7]. For example, in 2004, heart disease was noted on almost 70 % of diabetes-related death certificates among people aged 65 years or older and stroke was noted on 16 % of death certificates for the same group. It is generally accepted that adults with diabetes have heart disease death rates about two to four times higher than adults without diabetes and at least a similar risk for stroke [7].

Diabetes is the leading cause of kidney failure, accounting for over 40 % of new cases in 2008. In that same year, over 48,000 people with diabetes began treatment for end-stage kidney disease in the United States and more than 202,000 with end-stage kidney disease due to diabetes were on chronic dialysis or had received a kidney transplant [7].

Diabetic patients have a higher incidence of kidney disease because of microvascular damage to the glomerulus and small renal vessels. Baber and Auguste pointed out that chronic kidney disease and DM are highly prevalent among patients presenting with acute coronary syndromes. Consistent with the arguments already presented, they suggested that residual vascular risk remains disproportionately high in these populations primarily due to pre-existing vascular morbidity and the increase in overall cardiovascular risk occurs as a result [8•].

The focus on identifying patients with clinical diabetes or prediabetes who present to the ED with CVD is not only based on the observation that these patients tend to have poorer outcomes if they have diabetes. It is also the result of a more complex relationship between hyperglycemia, cardiovascular risk, and a third factor, renal insufficiency. DM is a known risk factor for CVD and plays a role in worsening the patient’s prognosis when in the presence of coronary artery disease, heart failure, hyperlipidemia and peripheral artery disease.

Diabetes has also been identified as a risk for HF that is partly but not entirely linked to coronary heart disease and hypertension. For example, associations have also been reported between absolute blood glucose levels, success of glycemic control, and HF. The Framingham Study firmly established the epidemiologic link between diabetes and HF [17]. The risk of HF was increased 2.4-fold in diabetic men and fivefold in diabetic women. When patients with prior coronary or rheumatic heart disease were excluded, the relative risk of HF remained elevated at 3.8 in diabetic men and 5.5 in diabetic women.

Similar findings have since been noted in a number of other studies. In a report of 9,591 subjects with T2D and matched controls, HF was more frequent at baseline in diabetics (11.8 vs 4.5 %). Among those free of HF at baseline, HF developed more often in diabetics during a 30-month follow-up. The incidence of HF in diabetic patients is even higher among elderly adults, who comprise the fast-growing demographic of ED patients [18].

A report from Kaiser Permanente of over 48,000 adults (mean age 58 years) with DM (predominantly T2D) and no evidence of HF were followed for a mean of 2.2 years. After adjustment for covariates, each 1 % increase in HbA1c was associated with an 8 % increased relative risk of HF [19].

A similar relationship was found between blood glucose levels and hospitalization for HF in a cohort of 31,546 adults (mean age 67 years) with high cardiovascular risk [20]. At a mean follow-up of 2.4 years, each 18 mg/dL (1 mmol/L) increase in baseline fasting plasma glucose was associated with a modest but statistically significant increase in the risk of hospitalization for heart failure.

Although the exact causal relationship has not been conclusively identified, small vessel disease, autonomic neuropathy, diastolic stiffness and decreased insulin availability to cardiac muscle have been proposed as a possible link between DM and HF.

DM may also have an impact on the severity of hyperlipidemia. The typical lipoprotein pattern in DM consists of moderate elevation in triglyceride levels, low HDL cholesterol values, and small dense LDL particles. This lipoprotein pattern is associated with insulin resistance and is present even before the onset of diabetes. Small dense LDL particles are highly atherogenic because of their enhanced susceptibility to oxidative modification and increased uptake by the arterial wall. At triglyceride levels >132 mg/dl, small LDL particles become common. It is well known that LDL cholesterol is one of the strongest independent predictors of CAD followed by low HDL cholesterol. Because hyperlipidemia and elevated blood glucose are both part of the metabolic syndrome, the natural question is whether there is a causal relationship between DM and hyperlipidemia as well—or at least a common pathophysiological pathway.

Al-Aqeedi and colleagues conducted a prospective study of 467 consecutive male patients hospitalized for ACS [21]. Of the 467 patients, 324 (69.4 %) fulfilled the criteria for metabolic syndrome. The most common abnormal metabolic components were elevated fasting blood glucose, reduced high-density lipoprotein cholesterol, and elevated triglycerides. The authors concluded that in ACS patients without previous history of DM, metabolic syndrome is highly prevalent and that elevated fasting blood glucose levels are an important part of that clinical spectrum. Whether the elevated glucose levels contributed to hyperlipidemia in these patients is unclear; however, elevated glucose levels clearly represent an important part of the relationship between metabolic syndrome and ACS.

Diabetes is also a risk factor for peripheral artery disease (PAD), which most commonly affects the arteries supplying the lower extremities. Restriction of blood flow due to arterial stenosis or occlusion often leads to intermittent claudication. Any further reduction in blood flow causes ischemic pain at rest, which can even affect the foot. Ulceration and gangrene may then supervene and can result in loss of the limb if not treated [22].

PAD affects approximately 12 million people in the US [23]. Data from the Framingham Heart Study revealed that 20 % of symptomatic patients with PAD had diabetes, but this probably underestimates the prevalence, since more people with PAD are asymptomatic than symptomatic [24]. Diabetes and smoking are the strongest risk factors for PAD [23].

Inflammation was already discussed as a key pathophysiological component in the development of vascular disease. It has also been established as both a risk marker and perhaps a risk factor for PAD. Elevated levels of C-reactive protein (CRP) are strongly associated with the development of PAD. Interestingly, levels of CRP are abnormally elevated in patients with impaired glucose tolerance and diabetes and may be involved with changes in the endothelium of major vessels. The endothelial lining of the arterial vasculature modulates the relationship between the cellular elements of the blood and the vascular wall, mediating the normal balance between thrombosis and fibrinolysis. The endothelial lining also plays an integral role in interactions between leukocytes and the cell wall. Thus, elevated blood glucose levels, perhaps through a common factor of CRP, may contribute to the inflammatory process and endothelial dysfunction associated with atherosclerosis and adverse outcomes [23]. In addition to PAD in the legs, another vascular system that appears to be affected by diabetes and hyperglycemia is the cerebral circulation.

Diabetes appears to play a role in the risk for cerebrovascular accident. In addition, incident hyperglycemia has been reported to augment acute ischemic brain injury in many human and animal studies. Possible mechanisms include increased brain tissue acidosis, increased blood–brain barrier permeability, and increased hemorrhagic transformation of the infarct. Whether acute hyperglycemia independently affects patient outcomes or whether this effect primarily reflects the effects of increased stroke severity or poor glycemic control has not been established [25].

Some patients who present to the ED may also have undiagnosed renal insufficiency. Kim and associates examined the effect of metabolic syndrome on clinical outcomes in patients with acute myocardial infarction (AMI) in the presence or absence of renal insufficiency. They enrolled 11,462 patients with AMI in a prospective Korean Acute Myocardial Infarction Registry. Participants were analyzed according to the presence or absence of both metabolic syndrome and renal insufficiency, with the primary endpoint being major adverse cardiac events, which included a composite of all-cause death, myocardial infarction, target lesion revascularization, and coronary artery bypass graft during the 1-year follow-up period. The results revealed that metabolic syndrome had a higher prevalence in patients with AMI who also had evidence of renal insufficiency with low glomerular filtration rate. In-hospital death and the composite endpoint were significantly higher in patients with metabolic syndrome than in those without. The 1-year mortality rate was also higher in patients with both metabolic syndrome and renal insufficiency, suggesting that the presence of renal insufficiency may have a negative impact on outcomes [26]. Diabetes is one of several causes of renal insufficiency, which may not always be clinically apparent when the patient presents.

Although the clinical implications of these findings is not completely clear, the authors suggested that CVD follows a different course in patients with DM with or without renal insufficiency but that renal insufficiency, if present, may play an additive role. Thus, patients with diabetes or prediabetes may benefit from being identified in the ED to allow for an alternate management strategy, which may include dose adjustments for diminished renal function or the choice of different agents.

When patients with prediabetes or DM come to the hospital, there is an opportunity to create a positive treatment continuum that begins in the ED and transitions to the inpatient service. This can be facilitated by the development of standard protocols to detect DM when the patient enters the ED and an ongoing collaborative relationship between the EPs and the hospitalist or other hospital-based medical personnel. With these systems in place, the goal would be to provide optimal glycemic control for the patient from the time he or she arrives until discharge. However, optimal glycemic control does not necessarily mean that the patient’s blood glucose level is maintained between 80 and 100 mg/dL at all times, nor does it mean that the same approach should be used in every patient. Insulin therapy is the recommend inpatient strategy and oral hyperglycemic medication should be discontinued until the patient is ready for discharge. Optimal glycemic control in a hospital setting will most likely be successful if the patient is managed with insulin therapy, so that accommodations can be made for changes that occur as a result of the underlying illness, therapeutic interventions or other factors that may not exist in the patient’s home environment. Insulin therapy can begin in the ED and preferably with basal insulin.

Optimal glycemic control is important for all critically ill patients [27, 28, 29]. In both the ED and hospital settings, insulin therapy is the preferred method for achieving glycemic control in most clinical situations. When possible, IV infusion is the preferred route of insulin administration; however, outside of acute treatment areas and critical care units, subcutaneous administration of insulin is used much more frequently. Orally administered agents should have a limited role in the inpatient setting [30••].

Continuous IV insulin infusion has been shown to be the most effective method for achieving specific glycemic targets in patients treated in the intensive care unit. Because of the very short half-life of circulating insulin, continuous IV delivery allows rapid dosing adjustments to address alterations in the status of patients. It is ideally administered by means of validated protocols that allow for predefined adjustments in the insulin infusion rate based on glycemic fluctuations and insulin dose [2•].

In a meta-analysis of the use of insulin therapy for critically ill hospitalized patients, Pittas and colleagues analyzed 35 trials. Combining data from all trials demonstrated that insulin therapy decreased short-term mortality by 15 %. In a subgroup analysis, insulin therapy decreased mortality in the surgical intensive care unit, when the aim of therapy was glucose control in patients with DM. A near-significant trend toward decreasing mortality was seen in patients with acute myocardial infarction who did not receive reperfusion therapy. The authors concluded that insulin therapy initiated in the hospital in critically ill patients has a beneficial effect on short-term mortality in different clinical settings [31].

Optimal glycemic control can have a positive effect on patient morbidity, length of hospital stay and the overall cost of care. In the DIGAMI 1 study, (Diabetes Mellitus Insulin-Glucose Infusion in Acute Myocardial Infarction) intensive insulin therapy for diabetic patients who were experiencing an acute myocardial infarction included an insulin-glucose infusion during the initial 24 h of hospitalization, followed by subcutaneous insulin four times daily for a minimum of 3 months [32]. Morbidity and mortality were assessed in the acute, subacute, and chronic phases. Acute effects, determined during the first 12–24 h after MI, included assessment of initial infarct size. Subacute effects (2–30 days) and chronic effects (>30 days) included the incidence of significant arrhythmias, re-infarction, congestive heart failure, and death.

The insulin-treated and the control groups had an approximately equal number of in-hospital complications, including ventricular fibrillation, re-infarction, high degree atrioventricular conduction disturbances, and congestive heart failure. Regardless of the treatment protocol received, the in-hospital courses were similar. Overall, patients had a mortality of 10.2 % in the hospital, 14.0 % at 3 months, and 22.4 % at 1 year. Though the infusion group had a slightly lower mortality than the control group in the hospital, at 3 months post-MI, and at 1 year, only the 1-year mortality was statistically significant. When examining mortality in the pre-stratified risk groups, the greatest mortality reduction is noted for patients who had never been on insulin before and were classified as low cardiac risk [32].

The DIGAMI 2 study was an international trial involving 3,000 subjects with a trial design similar to that of DIGAMI 1, enrolling persons with known diabetes or with initial glucose >11 mM/L (198 mg/dL) presenting with AMI with duration of symptoms <24 h. Study participants were randomized to 1 of 3 groups. Patients in the first group had a glucose/insulin infusion for at least 24 h and then were treated with subcutaneous insulin. The second intervention group was treated acutely with glucose/insulin infusion for at least 24 h and then returned to conventional treatment. The third intervention group received conventional treatment only. Although the study was discontinued early due to low recruitment, DIGAMI 2 did not support the acute introduction of long-term insulin treatment to improve survival in type 2 diabetic patients following myocardial infarction, when compared with a conventional management at similar levels of glucose control. In addition, insulin-based treatment did not lower the incidence of non-fatal myocardial reinfarction and stroke. However, an epidemiological analysis confirmed that the glucose level was a strong, independent predictor of long-term mortality in this patient category, underlining that glucose control seems to be an important part of their management [33].

Optimal glycemic control is also an important issue for patients with stroke. Williams et al. studied patients hospitalized with acute ischemic stroke over a 5-year period. Admission stroke severity, serial blood glucose levels, and new diabetes diagnoses were recorded. Hyperglycemia at admission to hospital was present in 40 % of patients with acute stroke. Patients with hyperglycemia were more often women and more likely to have prior diagnoses of diabetes and heart failure. In stroke patients, hyperglycemia independently increased the risk for death at 30 days, 1 year, and 6 years after stroke. The authors concluded that hyperglycemia at the time of admission was common among patients with acute ischemic stroke and was associated with increased short- and long-term mortality. They also suggested that a trial of intensive treatment of hyperglycemia should be considered for patients with acute stroke [25].

In another study, Alverez-Sabin and colleagues evaluated 268 consecutive patients with a nonlacunar middle cerebral artery (MCA) stroke at <3 h after onset, 27.2 % of whom were treated with tissue plasminogen activator (tPA) [34]. Serum glucose was determined at baseline before tPA administration. The results revealed that at baseline, 31 patients (42.5 %) were hyperglycemic. Early reperfusion (<6 h) occurred in 43 patients (58.9 %); however, admission blood glucose correlated negatively with the degree of neurological improvement at 24 h in reperfused but not in nonreperfused tPA-treated patients. Factors associated with poor outcome were increased age, history of DM, admission glucose >140 mg/dL, and early reocclusion among reperfused patients. Only admission glucose value >140 mg/dL emerged as an independent predictor of poor outcome despite tPA-induced recanalization. The authors concluded that hyperglycemia before reperfusion may in part counterbalance the beneficial effect of early restoration of blood flow, which translates into a worse outcome in hyperglycemic patients despite tPA-induced recanalization.

DM is frequently not diagnosed until complications appear, and approximately one-quarter of all people with diabetes in the US may be undiagnosed [2•]. The effectiveness of early identification of prediabetes and diabetes through mass testing of asymptomatic individuals has not been validated, and rigorous trials to provide such proof are unlikely to occur.

Recognition of the disease in the ED and inpatient setting is, however, useful. Testing to detect T2D and prediabetes in asymptomatic people should be considered in adults of any age who are overweight or obese (BMI ≥25 kg/m²) and who have one or more additional risk factors for diabetes.² In those without these risk factors, testing should begin at age 45 years. If tests are normal, repeat testing at least at 3-year intervals is reasonable. To test for diabetes or prediabetes, the A1C, FPG, or 75-g 2-h OGTT are appropriate tests. In those identified with prediabetes, identify and, if appropriate, treat other CVD risk factors such as hyperlipidemia, elevated blood pressure and obesity.

Patients with diabetes are more likely to be hospitalized and to have longer durations of hospital stay than those without diabetes. From the standpoint of treatment, as mentioned previously, the 2009 ADA/AACE Guidelines suggest that patients with diabetes should be switched from oral agents to insulin therapy while they are inpatients [30••]. The management of hyperglycemia in the hospital presents unique challenges that stem from variations in a patient’s nutritional status and level of consciousness, dietary restrictions for diagnostic testing, the practical limitations of intermittent glycemic monitoring, and the ultimate importance of patient safety. Accordingly, reasonable glucose targets in the hospital setting are modestly higher than may be routinely advised for patients with diabetes in the outpatient setting, and adequate control may best be achieved by switching a patient from oral agents to insulin [30••].

Together, these studies suggest that identification of patients with diabetes before they are admitted to the hospital may provide an opportunity to optimize glycemic control with the goal of better outcomes, shorter hospital stays and lower overall cost of care.

The transition of care from the ED to the hospital medicine service represents a common step in the continuum of care but its impact may be underappreciated, especially in patients who present with DM and may have significant comorbidities. The clinical significance between DM and comorbid conditions is highlighted in the relationship between acute coronary syndrome and diabetes. Diabetes increases the risk of atherosclerosis in at least three ways and with this inextricable relationship between diabetes and cardiovascular disease in mind, identification of diabetes in patients who present with cardiovascular problems is essential to a smooth transition of care to the inpatient service. There is an opportunity to create a positive treatment continuum that begins in the ED and transitions to the inpatient service. This can be facilitated by the development of standard protocols to detect diabetes when the patient enters the ED and an ongoing collaborative relationship between the emergency physicians and the hospitalist or other hospital-based medical personnel. With these systems in place, the goal should be to provide optimal glycemic control for the patient from the time he or she arrives until discharge and thereafter.
