Inflammatory pseudotumor-like follicular dendritic cell tumor of the liver with expression of estrogen receptor suggests a pathogenic mechanism: a case report and review of the literature
- 133 Downloads
Abstract
The term inflammatory pseudotumor-like follicular dendritic cell tumor has been suggested for a follicular dendritic cell tumor of the liver associated with a dense inflammatory infiltrate and Epstein–Barr virus infection. This tumor is less aggressive than usual intraabdominal follicular dendritic cell sarcoma and shows a strong female predominance; however, the pathogenesis is uncertain. We report the case of a 59-year-old woman who presented with a 6-cm mass in the liver. Histological examination showed spindle cells with a storiform pattern and prominent inflammatory infiltrate mimicking inflammatory pseudotumor. Spindle cells expressed follicular dendritic cell markers CD21 and CD35, and were positive for Epstein–Barr virus-encoded RNA and LMP-1 protein. In addition, neoplastic cells expressed estrogen receptor (ER). Fifteen cases of inflammatory pseudotumor-like follicular dendritic cell tumor of the liver including the case we describe here have been reported in the literature. A review of the literature disclosed that normal follicular dendritic cells may express ER; however, extensive testing has not been previously reported in follicular dendritic cell sarcoma. The female predominance and the expression of ER in the case we report are suggestive of a hormonal role in the pathogenesis and therapy of inflammatory pseudotumor-like follicular dendritic cell tumor of the liver.
Keywords
Inflammatory pseudotumor Follicular dendritic cell tumor Epstein–Barr virus ER LiverIntroduction
Inflammatory pseudotumor (IPT) encompasses a heterogeneous group of disorders, both nodal and extranodal, usually considered reparative, characterized by a prominent inflammatory infiltrate admixed with proliferating spindle cells, and historically considered as myofibroblasts [1]. Inflammatory pseudotumor involves diverse anatomic sites including lung, gastrointestinal tract, and lymph nodes [2]. A subset of lesions of inflammatory pseudotumor involving soft tissues of children and young adults have been reclassified as inflammatory myofibroblastic tumors because of clinical behavior of recurrence, the uniform cellularity of myofibroblasts including cellular atypia, and the presence of chromosome 2p23 translocations with overexpression of ALK-1 gene [3]. More recently, lesions with features of IPT mainly involving the liver and spleen were found to predominate in females, and composed of variable amounts of spindle cells with follicular dendritic cell or smooth muscle differentiation, however, clinically less aggressive than other intraabdominal follicular dendritic cell sarcoma. In addition, these tumors showed a strong association with Epstein–Barr virus (EBV) [4]. Because of these distinctive features, Cheuk et al. [5] suggested the term of inflammatory pseudotumor-like follicular dendritic cell tumor (IPT-FDCT) for these lesions. Clonality of episomal EBV genome, recurrence, and rare metastasis support the neoplastic nature of the hepatic lesions [6].
Although EBV appears involved, the pathogenesis of these lesions remains uncertain. Of 14 cases of IPT-FDCT of liver that have been reported in the English literature, there is a strong female predominance, suggesting that hormonal factors may play a pathogenic role. Herein, we report the case of a 59-year-old woman with IPT-FDCT of the liver who demonstrated expression of estrogen receptors (ER) in neoplastic spindle cells. Therefore, we searched the literature for the status of sex hormone receptors in published cases of IPT-FDCT of the liver and discuss the possible role of ER in the pathogenesis of this neoplasm.
Report of a case
An asymptomatic 59-year-old Chinese woman presented for a routine health check-up. Patient did not refer abdominal pain, fever, weight loss, or constitutional symptoms. Abdominal computed tomography scan revealed a mass lesion in the left hepatic lobe with features suspicious for hepatocellular carcinoma. Ultrasound examination also identified a 6.0 × 5.2-cm hepatic lesion, without other abdominal abnormalities. Chest X-ray result was normal. Laboratory testing showed normal liver function tests; serum α-fetoprotein was 1.51 ng/mL (normal range, <9.0 ng/mL) and carcinoembryonic antigen was 2.9 ng/mL (normal range, <5.0 ng/mL). Serologic testing results for hepatitis B surface antigen, and hepatitis A, C, D, and E antibodies were all negative. A partial hepatectomy was performed, and the mass lesion was entirely removed.
Material and methods
Clinical history
Clinical history was retrieved from the patient medical chart in the Office of Medical Record at Guangdong General Hospital, China. Clinical follow-up was performed through questionnaire form.
Histopathology
Immunohistochemical studies
The resected surgical specimen was sliced and then fixed in 10% buffered formalin. Representative sections were taken for routine histologic processing and paraffin embedding. The tissue blocks were cut into 4-μm sections and were stained with hematoxylin and eosin (H&E). Immunohistochemical staining was performed on formalin-fixed and paraffin-embedded tissue sections with Avidin–biotin–peroxydase complex after antigen retrieval in a steamer. Antibodies from Dako, Denmark and other companies for the staining included ALK-1 (1:50), Bcl-2 (1:50), CD1a (1:400), CD8 (1:100), CD20 (1:800), CD21 (1:50), CD23 (1:50), CD30 (1:100), CD34 (1:200), CD35 (1:20), CD45 (1:800), CD68 (1:200), CK (1:100), Desmin (1:50), EMA (1:200), ER (1:50), Granzyme B (1:200), Ki67 (1:100), MPO (1:8,000), p53 (1:500), PR (1:50), S-100 (1:2,000), SMA (1:100), Vimentin (1:200); CD4 (1:10), CD3 (Novacastra, Newcastle upon Tyne, UK,1:100), HMB45(1:50), CD15 (Labvision, USA, 1:50), LMP-1 (Cell Marque, 1:1), and TIA-1 (Immunotech, 1:1,000). Appropriate positive and negative controls were evaluated simultaneously.
In situ hybridization for EBV
In situ hybridization for EBV-encoded small RNA (EBER) was performed on formalin-fixed, paraffin-embedded tissue sections using fluorescein isothiocyanate (FITC)-labeled peptic nucleic acid (PNA) probes against EBER (code Y5200; Dakopatts, Glostrup, Denmark). A positive signal was detected with a biotin-free, anti-FITC horseradish peroxidase-conjugated antibody. The reaction was performed with Dako PNA ISH detection Kit (Dako A/S). A known positive control was evaluated to ascertain the sensitivity of the assay.
Ultrastructural analysis
Multiple pieces of tissue sampled at about 1 mm from the tumor were fixed in 3% glutaraldehyde and then post-fixed in 1% osmium tetroxide. The tissue embedded in epoxy resin was cut to 1 μm of thickness and stained in toluidine blue solution. Appropriate blocks were chosen for ultrathin sectioning and the sections were stained with uranyl acetate and lead citrate. Electron microscopic examination was performed using a Philips CM 100 machine under 80 kV accelerating voltage.
Results
Macroscopic findings
The resected specimen contained a well-circumscribed, unencapsulated mass lesion measuring 6.0 × 4.5 × 3.0 cm. The cut surfaces were tan and fleshy with punctated dark red to yellow areas of hemorrhage and necrosis, respectively. No satellite nodules were identified.
Histologic findings
a Inflammatory pseudotumor-like follicular dendritic cell tumor (IPT-FDCT) shows partial encapsulation with dense inflammatory infiltration; normal hepatic tissue present in the right lower field (H&E stain, original magnification ×40). b Foci of coagulative necrosis and hemorrhage are noted (H&E stain, original magnification ×400). c The tumor shows spindle cells arranged in short fascicles mixed with infiltrate of small lymphocytes and plasma cells (H&E stain, original magnification ×400). d A storiform pattern formed by the spindle cells is highlighted by strong CD21 stain (original magnification ×100). e Immunohistochemistry shows nuclei of the spindle cells positive for ER (original magnification ×400). f In situ hybridization for EBER showing nuclear and cytoplasmic reactivity of the spindle cells (original magnification ×400)
Immunophenotypic findings
Summary of clinical features of 15 cases of inflammatory pseudotumor-like follicular dendritic cell tumor of the liver
| Case | Author (year) | Age/sex | Presentation | Size (cm) | Lobe | Treatment | Outcome |
|---|---|---|---|---|---|---|---|
| 1 | Selves [6] (1996) | 68/F | Malaise, weight loss, anemia | 11 | Left | Chemotherapy; partial hepatectomy | Alive at 30 months |
| 2 | Shek [9] (1996) | 35/F | Epigastric discomfort, fever, weight loss | 20 | Right | Hemihepatectomy | Recurred at 30, 48, and 60 months; died at 95 months from dissemination in peritoneum |
| 3 | Poon [10] (1997) | 38/F | Hepatomegaly, ultrasound and CT scan showed a large liver tumor at the right lobe | 20 | Right | Extended hemihepatectomy | Recurrence at 32 and 39 months, and alive at 51 months |
| 4 | Shek [11] (1998) | 37/M | Malaise, weight loss of 5 kg | 15 | Right | Trisegmentectomy with caudate lobectomy | Alive at 42 months |
| 5 | Cheuk [5] (2001) | 19/F | Right upper quadrant pain, weight loss, palpable abdominal mass | 12 | NA | Excision | Alive at 40 months |
| 6 | Cheuk [5] (2001) | 56/F | Gastrointestinal upset | 15 | Right | Right hepatectomy | Recurrence at 15, 27, and 48 months, alive at 56 months |
| 7 | Cheuk [5] (2001) | 40/F | Epigastric pain, weight loss | 12.5 | Left | Left hepatectomy | Recurrence at 108 months |
| 8 | Cheuk [5] (2001) | 49/F | Liver mass on ultrasound during routine health check-up | 4.2 | NA | Excision | Alive at 9 months |
| 9 | Cheuk [5] (2001) | 31/F | Abdominal distention, weight loss | 15 | Right | Hemihepatectomy | Alive at 60 months |
| 10 | Chen [12] (2001) | 57/F | Epigastralgia, weight loss | 9.5 | Left | Refused resection; on steroid with tumor progression | Alive at 3 years (36 months) |
| 11 | Chen [12] (2001) | 51/F | Abdominal discomfort, weight loss | 12 | Left | Left lobectomy | Alive at 12 months |
| 12 | Torres [13] (2005) | 82/M | Weakness, occasional fevers, anorexia, 9-kg weight loss, one episode of syncope | 15 | Right | Right hepatic lobectomy | Alive at 18 months |
| 13 | Bai [14] (2006) | 30/F | Liver mass on ultrasound during health check-up | 5.5 | Right | Right lobectomy | Alive at 24 months |
| 14 | Granados [15] (2008) | 57/F | Abdominal pain,vomiting, dizziness, and a large hepatic mass by ultrasound | 13 | Left | Resection of the tumor | Alive at 24 months |
| 15 | Current (2010) | 59/F | Liver mass on CT during routine health check-up | 6 | Left | Partial hepatectomy | Alive at 17 months |
In situ hybridization for EBER showed an intense nuclear and cytoplasmic stain in many of the spindle cells (Fig. 1f). The background small lymphocytes and plasma cells were negative.
Electron microscopic findings
An electron microscopic photograph shows ultrastructure of spindle cells with long villous cell processes and desmosomes (arrow). No complex junctions, cytoplasmic interdigitations, or Birbeck granules were identified
Discussion
IPT-FDCT of the liver is a recently described rare tumor and considered as a variant of follicular dendritic cell sarcoma, with predominance in females, however, clinically less aggressive than usual intraabdominal follicular dendritic cell sarcoma. It is characterized by a mixture of chronic inflammatory cells and variable amounts of spindle cells with follicular dendritic cell differentiation, usually expressing EBV. IPT-FDCT is distinct from the more common IPT which is a reparative process that involves diverse anatomic sites, including lung and gastrointestinal tract [2], and when involving liver, usually is associated with bile duct obstruction and can regress with antibiotic therapy [7, 8].
Summary of immunophenotypic profile of the tumor cells
| Markers | Results |
|---|---|
| CD21 | + |
| CD35 | + |
| EBV-LMP1 | + |
| ALK1 | − |
| Pan-CK | − |
| EMA | − |
| CD15 | − |
| CD30 | − |
| CD68 | − |
| SMA | − |
| Desmin | − |
| S100 | − |
| Bcl-2 | − |
| CD34 | − |
| CD45 | − |
| CD1a | − |
| Myeloperoxidase | − |
| HMB45 | − |
Immunohistochemical profile of 15 cases of inflammatory pseudotumor-like follicular dendritic cell tumor of the liver
| Markers | Number of cases (+/total) | Positive (%) |
|---|---|---|
| Actin | 1/2 | 50 |
| ALK | 0/7 | 0 |
| CD1a | 0/1 | 0 |
| CD21 | 10/10 | 100 |
| CD21/CD35 | 5/5 | 100 |
| CD23 | 7/12 | 58 |
| CD35 | 7/9 | 78 |
| CD68 | 1/4 | 25 |
| Clusterin | 1/1 | 100 |
| CNA.42 | 8/8 | 100 |
| Desmin | 0/3 | 0 |
| EBER | 13/14 | 93 |
| Ki-M4P | 3/3 | 100 |
| LMP-1 | 7/8 | 86 |
| R4/23 | 2/2 | 100 |
| S-100 | 0/6 | 0 |
| SMA | 7/12 | 58 |
| Vimentin | 5/5 | 100 |
A review of the immunohistochemical reactivity of 15 cases [5, 6, 9, 10, 11, 12, 13, 14, 15] revealed that 10/10 (100%) cases were positive for CD21, 7/9 (78%) positive for CD35, and five cases were either strongly positive or partial weak positive for a CD21/CD35 cocktail. Expression for other follicular dendritic cell markers was also observed, including 8/8 (100%) for CNA.42, 3/3 (100%) for Ki-M4P, and 2/2 (100%) for R4/23. Variable expression of muscle-associated antigens was noted: 1/2 (50%) for actin, 6/9 (67%) for HHF35, and 1/3 (33%) for smooth muscle actin. No desmin expression was identified in three tested cases. The neoplastic cells were negative for ALK-1, S100, EMA, and cytokeratin.
The pathogenic mechanism of EBV in IPT-FDCT of the liver is unclear as IPT-FDCT of spleen and IPT. IPT comprises a group of heterogeneous diseases; a portion of the disease is associated with abnormal function of ALK1 and some are associated with EBV infection. The progenitor cells infected by EBV appear different in IPT from those in IPT-FDCT. Our report supports that IPT-FDCT belongs to EBV-associated neoplasms. Most hepatic IPT-FDCT was associated with EBV, which specifically infected spindle-appearing dendritic cells. EBER and/or LMP-1 were reported in 13/14 (93%) of cases. The most sensitive mean of detecting EBV infection in tissues is through EBER testing, while LMP-1 immunohistochemistry is less sensitive [4]. LMP-1 gene is considered an EBV oncogene and is capable to transform rodent fibroblasts in vitro. EBV genome with point mutations or 30-bp deletion in exon 3 of LMP-1 gene is prevalent in Asia and was identified in one of two hepatic IPT-FDCT reported by Chen et al. [12]. No EBV was identified in 24 cases of extranodal FDCS reviewed by Shia [16]. EBV was identified by LMP-1 or EBER only in the neoplastic spindle cells, but not in the lymphocytes or plasma cells, suggesting a pathogenic association of EBV. Clonal EBV genome was identified in hepatic IPT-FDCT [6, 12], which suggests that EBV infection was an early event in the transformation of the tumor precursor cells. However, multiple genetic mutations are required for malignant transformation, which are largely unknown for IPT-FDCT.
Since there is marked female predominance among cases of IPT-FDCT of the liver, it is tempting to suggest that female hormones or their receptors may contribute to growth of follicular dendritic cell tumors infected by EBV. A synergistic role of EBV and ER is speculated in the pathogenesis of IPT-FDCT; however, no evidence has been identified about this and studies about the interaction of EBV and ER have not been reported in literature. Sapino et al. [17] reported ER protein overexpression and increased mRNA of ER in normal follicular dendritic cells, which paradoxically became more prominent after tamoxifen therapy in cases with breast cancer. They also reported negativity for ER of two cases of follicular dendritic cell sarcoma. Our review of the literature did not reveal other reports of ER status in follicular dendritic cell sarcoma or in IPT-FDCT. The significance of ER expression in this case of IPT-FDCT of the liver raises the possibility that ER contributed to tumor growth. In comparison, it is acknowledged that desmoids tumor, also known as extraabdominal fibromatosis, also has a strong female predominance and ER overexpression in approximately 90% of cases; tamoxifen has been reported effective in adjuvant therapy of desmoids tumor, suggesting that the tumor is hormone-dependent [18]. If the association between IPT-FDCT and ER overexpression is confirmed, ER could be evaluated as a potential therapeutic target.
In summary, IPT-FDCT of the liver is a neoplasm of follicular dendritic cells admixed with abundant inflammatory cells and shows a strong association with EBV infection. It is less aggressive than the usual intraabdominal follicular dendritic cell sarcoma, but shows recurrences, thus surgical resection is the treatment of choice. The pathogenesis is uncertain and is puzzling in its strong predominance in females, thus, we tested one of these tumors for ER and demonstrated its expression in the tumor cells, similar to what occurs in normal follicular dendritic cells, but apparently not in follicular dendritic sarcoma as reported previously. This finding warrants a systematic evaluation for ER in follicular dendritic cell sarcoma and IPT/FDCT because of the potential for a specific therapeutic target.
Notes
Acknowledgement
We thank Dr. Hengguo Zhuang and Dr. Minghui Zhang for diagnostic consultation and are grateful to Xinlan Luo for expert technical assistance.
Conflict of interest
The authors declare that they have no conflict of interest.
