The Classic: Repair of Bone in the Presence of Aseptic Necrosis Resulting from Fractures, Transplantations, and Vascular Obstruction

The fate of bone which undergoes aseptic necrosis as a result of circulatory disturbance varies considerably, according to the environment of the necrotic area. If the necrotic bone is attached to and directly continuous with living bone, there is ingrowth of vessels and of fibrous and osteogenic tissues from the living into the necrotic area. There is usually survival of unossified osteogenic elements about the periphery and ends of the area that has had its circulation interrupted. By the process of creeping substitution the old bone is gradually absorbed and replaced by new bone, so that in the course of months or occasionally years the necrotic area is more or less completely transformed into a living one. Whether the amount of new bone formed is as great as the amount of bone which died depends largely on the extent of living bone with which it is in contact and the amount of osteogenic elements surviving about its periphery. When these are both extensive, there may be complete replacement of the dead bone by new bone; but when limited, bone absorption may be greatly in excess of bone formation, so that incomplete replacement results with the formation of bone that is less dense than the original and that shows varying degrees of cavitation. Functional stimulation also plays an important role in the rate and degree of transformation. In general the greater the degree of function, the greater the rate and degree of transformation into new bone. If the necrotic bone is largely or wholly intra-articular and extensively bordered by articular cartilage, the attachment to the surrounding soft parts will be markedly limited and chances for revascularization and transformation will be greatly reduced. Thus, injury to vessels may be the cause of some of the cases of Kienböck’s malacia of the carpal lunatum and of Legg-Perthes’ disease,—as when it follows reduction of congenital dislocation of the hip.

Operations which involve severence of bone or extensive separation of soft parts from bone may occasionally interfere with blood supply sufficiently to cause massive necrosis. An example of this is the necrosis of the head and neck of the femur in the following case in which arthroplasty of the hip was performed.

CASE 1. Male, age twenty-eight, entered the University of Chicago Clinics May 7, 1929, because of bony ankylosis of the left hip resulting from acute hematogenous pyogenic arthritis two and one-half years previously (Fig. 1). At operation on May 9, through a goblet incision the greater trochanter was reflected, the soft parts reflected from the neck, and the head detached from the acetabulum with a chisel. After roughly rounding it off and deepening the acetabulum, a cap of free fascia lata was placed over the head and tied about the neck with a purse-string suture of chromic catgut. The head was then restored to acetabulum, the muscles and greater trochanter were sutured in place, the wound closed, and a body and leg cast applied. There was slight postoperative febrile reaction, but the temperature returned to normal at the end of ten days and the wound healed with only a slight superficial serous discharge. The cast was removed after two weeks and weight extension applied for ten days. A roentgenogram taken twenty days postoperatively (Fig. 2) showed the reduced head of the femur with its sharply outlined chisel cuts resting in the acetabulum. Movement was begun and after five weeks the patient was allowed to walk with crutches. In a roentgenogram taken thirty-six days postoperatively (Fig. 3) the head and neck showed their outline and density unchanged, but there was a slight reduction in density in hone at the junction of neck and shaft and slight atrophy of disuse of the shaft. A fair range of mobility persisted in the hip but it remained painful so that the patient continued to walk on crutches. A roentgenogram taken 151 days postoperatively (Fig. 4) showed the head retaining its original density and sharp outline of its cut surface. The adjacent innominate bone and the trochanters and shaft of the femur showed marked atrophy of disuse. The zone of reduced density at the base of the neck had broadened to include almost the entire neck of the femur. A diagnosis was made of necrosis of the head and neck of the femur with retention of the original density of the head and atrophy of disuse of the surrounding living bone. The extension of the rarefaction in the neck was interpreted as evidence of beginning invasion of the necrotic portion by tissue from the living portion with absorption of the dead bone and replacement by a less dense living bone. The hip improved slowly and the patient began to bear a small amount of weight on it. A roentgenogram 250 days postoperative (Fig. 5) showed persistence of the atrophy of the shaft and innominate bone and a very marked reduction in the density of the shadow cast by the head as compared with the previous roentgenograms. The cortex at the inferomesial and superolateral portions of the base of the head retained its old density but the cancellous bone of the interior and articular surfaces of the head had been reduced to practically the same density as the trochanters and upper end of the shaft. This was interpreted as evidence of extensive invasion of the head with absorption of the dead bone and a certain amount of replacement by new bone. The patient then made greater use of the limb in weight-bearing but continued to assist it with a crutch. A roentgenogram taken 350 days after operation showed slight increase in density of all of the atrophic living bone in the region and slight further reduction in the dense areas of the head. The patient then walked with the assistance of a cane, and a roentgenogram taken 404 days postoperatively (Fig. 6) showed little change except for evidence of cavitation in the inferomesial part of the head, indicating absorption of the necrotic bone with failure of replacement by new bone.

Open image in new window

Open image in new window

Open image in new window

Open image in new window

Open image in new window

Open image in new window

The hip showed about forty degrees of flexion but marked limitation of abduction and rotation. Its strength had gradually improved and there was only slight discomfort in walking unless it was prolonged.

The cause for this exceptional occurrence of necrosis of head and neck without sequestration appeared to lie in the traumatism of head and denudation of neck of its covering of soft parts. However, it may have been due in part to deep-seated mild infection in the region of the new joint, despite the absence of discharge from that region. Failure of the necrotic head to be sequestrated speaks decidedly in favor of aseptic instead of septic necrosis although sequestration may not occur in the presence of mild infection of a necrotic area. In another case I observed necrosis of the head and neck following an arthroplasty in which there was infection of the wound with a purulent discharge, but the dead bone was sequestrated in the course of several weeks. In the case here reported functional stimulation of the bones resulting from movement of the joint, combined with protection of the necrotic head from weight-bearing, was followed by creeping substitution of the necrotic bone by new bone in the greater part of the head without either erosion of dead bone or the development of marked deformity.

Extensive separation of periosteum from bone, particularly during the growing period, with resultant injury of nutrient and metaphyseal vessels may result in extensive aseptic necrosis of bone. Brunschwig of the University of Chicago has produced areas of necrosis in the femur and tibia of young dogs varying up to nearly the entire extent of the shaft. There is absence of sequestration, and creeping substitution of the necrotic bone takes place by new bone, formed from the adjacent living bone and the surviving osteogenic elements of the separated bone and periosteum with only slight changes in size, shape, and density. Such bone necrosis is no doubt occasionally produced by extensively denuding operations, but it remains undetected as the damaged area is repaired without appreciable alteration in the clinical course of the disease.

Fracture may cause necrosis by interference with the blood supply of the bone in the immediate vicinity of the break or by damage to larger vessels that furnish a large part or all of the nutrition to one of the fragments.

Cornil and Coudray [5] found that in experimental fractures there is necrosis of the cortex for a variable distance back from the fragment ends which is gradually replaced by new bone ingrowing from the living cortex with which it is continuous and to a less extent from the adjacent callus. This occurrence does not interfere with the process of healing. In fact, it has even been claimed that the presence of the necrotic bone is a stimulus to bone repair. Non-union and neck absorption in fractures of the femoral neck have probably been wrongly attributed to the marginal necrosis of fragment ends. Clinically I have not seen evidence of any appreciable amount of bone necrosis extending back into the fragment ends from the fracture line, either at operation or in roentgenograms. A narrow strip of fragment end may be bare and white when a simple fracture of some standing is exposed at operation; but I have never seen the fragment ends appear appreciably denser than the cortex some distance back from the fracture as shown by roentgenograms of fractures, either united or ununited, of several weeks’ standing, where the regional bone had undergone atrophy of disuse. The indications are that such bone as becomes necrotic at the ends of vascularized fragments is rapidly revascularized by ingrowth from the living bone and is absorbed and reduced in density about as rapidly as is the adjacent living bone from atrophy of disuse. In histological sections of resected ends of fragments from cases of delayed union or nonunion, I have not seen extensive amounts of dead bone and that which I have found showed signs of creeping substitution by new bone.

In the case of fractures followed by bony union, marginal necrotic bone may rarely be absorbed more rapidly than new bone is deposited, thereby creating a zone of reduced density in the region of the fragment ends. It is seen in pathological fractures of osteomalacia, osteogenesis imperfecta, and in bone diseases associated with parathyroid adenoma and is known in the German literature as Losser’s Umbauzone [6] (zone of transformation). I saw it once in a patient who had no general bone disturbance but a refracture of the ulna one year after the original fracture had been successfully treated by an autogenous inlay bone graft. Following the refracture a second bone graft was inserted in the accompanying fractured radius which had failed to unite following the first transplantation. Three and onehalf months afterwards the radius was united, but a zone of reduced density had developed along the oblique fracture line in the ulna although no motion could be elicited. Six and a half months later the zone was slightly narrowed and increased in density and eleven months later it had fully ossified. This zone apparently resulted from absorption of marginal necrotic bone produced by the fracture with marked delay in replacement by new bone for some unexplained reason.

Necrosis of bone may also occur in fractures bordering on joints from injury to the blood vessels to a large part or all of the joint fragment. It undergoes either partial or total necrosis. The condition may be met with in intracapsular fractures of the neck of the femur, of the capitellum humeri, of the carpal navicular, of the head of the radius and of the neck of the astragalus, and it always follows complete detachment of small fragments in intra-articular fractures.

Necrosis of the proximal fragment in complete intracapsular fracture of the neck of the femur occurs in a not inconsiderable percentage of the cases. Santos [7] has recently completed a detailed study which has thrown light on many aspects of the condition. A summary of his report follows: Necrosis may occur in fractures at any age, and although relatively more frequent in older persons, it is often absent in them. This may sometimes be because of blood reaching it by way of vessels in the untorn periosteum. The vessels of the ligamentum teres may supply adequate blood to keep the head alive even in the aged.

Death of the proximal fragment predisposes to non-union, but union occurs in a considerable percentage of the cases with a dead head in which there is impaction of fragments or in which there is efficient reduction and fixation of fragments, the best results apparently being obtained from the closed abduction method of Whitman. At the end of the period of immobilization the distal living fragment usually shows roentgen-ray signs of reduced density due to atrophy of disuse, but the necrotic head which cannot atrophy casts practically as even and heavy a shadow as at the time of fracture. This usually makes it possible to diagnose necrosis roentgenologically at this stage.

If bony union occurs the head is gradually invaded by the ingrowth of tissue from the distal fragment and sometimes from the hypertrophied round ligament. The necrotic marrow is replaced by vascular connective tissue and eventually by bone marrow, but the necrotic bone is much more slowly absorbed and replaced by a variable amount of irregularly arranged living bone. The necrotic cartilage is slowly absorbed and replaced by fibrous tissue, fibro-cartilage, and to some extent eventually by new hyaline cartilage. If too much weight is borne on the head before it has been transformed into new bone, its weight-bearing portion may collapse with a resultant deformity and a poor functional result, but this may be averted by prolonged avoidance of weight-bearing. The functional stimulation which comes from motion of the limb without weight-bearing is sufficient to hasten transformation of the head.

If non-union results, the neck fragments are gradually more or less completely eroded and the remaining surfaces usually become more or less adherent to the capsule and to each other. The marrow spaces of the dead and non-functioning head are gradually invaded by vascularized connective tissue by way of the round ligament and in some cases by way of the adhesions. Absorption of the invaded old bone and partial replacement by new bone either does not take place at all, at least for many months, or it goes on very much slower than is the case when bony union takes place and the head is subjected to functional stimulation. The head casts a shadow for at least one to two years that is denser than that of the neighboring living bone which is atrophic from disuse. These points are illustrated by Fig. 7 showing a dense necrotic head in a case of ununited fracture of the neck of the femur of sixteen months’ duration and by Fig. 8 which is a roentgenogram of a slice of the excised head. Although both bone and marrow were dead and about one-half of the marrow space was reinvaded by connective tissue from the round ligament, there was no absorption of the dead bone except about the fovea, where there was also a small amount of newly formed bone. Eventually absorption and partial replacement of the dead head by new bone is brought about and the head may remain as a cavitous hull or in rare cases it may be completely absorbed. The bearing of these findings on prognosis and treatment are brought out in Santos’s article.

Open image in new window

Open image in new window

In fracture of the neck of the os calcis the body may rarely have so much of its blood supply cut off that it undergoes extensive necrosis. Its subsequent history is analagous to that of a necrotic proximal fragment in intracapsular fracture of the neck of the femur. If bony union between the fragments follows, the necrotic body will be invaded gradually by blood vessels, fibrous, osteogenic, and myelogenous tissue, and a gradual replacement of the necrotic by living elements will be brought about. The replacement may be incomplete and the necrotic portion located farthest from the fracture may be broken down by weight-bearing before the ingrowing tissue reaches it, thereby leading to deformity and permanent derangement of the bone.

The following cases are illustrative of this condition.

CASE 2. Male, aged twenty-six, sustained a fracture at the junction of body and neck of the astragalus with complete dorsal dislocation of the body, the posterior capsule being the only remaining attachment. It was reduced by open operation and a cast applied which was worn for nine weeks. A roentgenogram taken seventy-four days after injury (Fig. 9) revealed marked reduction in density of the bones of the foot and the vicinity of the ankle, except the body of the astragalus which cast a shadow of normal density. The fracture appeared to he uniting, but the fracture line on the body fragment was irregular and worm-eaten, indicating invasion and absorption by tissue from the distal fragment. The diagnosis was made of aseptic necrosis of the body of the astragalus as indicated by the preservation of its normal density while the surrounding bone underwent atrophy of disuse. The patient had stiffness and weakness in the ankle and walked with crutches. A roentgenogram taken 160 days after injury revealed appearance of further invasion and reduction in density of the body of the astragalus with preservation of its bony articular cortex (Fig. 10). The patient was then lost sight of.

Open image in new window

Open image in new window

CASE 3 is that of a five-year old boy who fell twenty-two feet, sustaining a fracture at the junction of the neck and body of the left astragalus with little displacement of fragments and a fracture of the posterior superior portion of the os calcis (Fig. 11). A foot and leg cast was worn for six weeks, after which the patient gradually began to walk on the limb; but stiffness and pain persisted, causing a considerable amount of disability. A roentgenogram taken 274 days after the injury (Fig. 12) showed union of the fractures in both astragalus and os calcis but the body of the os calcis had undergone extensive change. There was irregular increase in density of the distal and inferior portion of the proximal fragment, which was due to newly formed bone, but the superior and posterior portions bordering on the ankle joint were reduced in volume and irregularly in density,’ and the shadow of articular surface was lost in almost its entire extent. There was a small island of bone in the posterior articular portion of the body. The body had apparently become necrotic; its distal portion had been invaded and replaced by new hone, but the articular portion had broken down from weight-bearing, before being invaded and partially absorbed by vascularized connective tissue. Walking was continued with little improvement of symptoms. A roentgenogram taken fourteen and a half months after the injury showed still further irregularity and reduction in volume of the body of the os calcis. Eighteen months after the injury (Fig. 13) there was little change in appearance except that the island of bone posteriorly had increased considerably in size. Another roentgenogram twenty-three months after injury showed the changes in the body had remained practically stationary, but the articular surface was more regular in outline. The island of bone in the posterior part of the body was interpreted as a transformed necrotic portion that had become revascularized with gradual growth of the bony center.

Open image in new window

Open image in new window

Open image in new window

The blood supply of the astragalus is derived mainly from a branch of the arteria dorsalis pedis which traverses the sinus tarsi lateral to the neck and breaks up to enter the bone near the junction of the neck and body along the lateral and inferior surfaces. There are very small branches entering the bone mesially and posteriorly at points of ligamentous and capsular attachments. Apparently when there is a fracture along the junction of body and neck the important vessels to the body are interrupted and there may be insufficient circulation through the remaining vessels, so that aseptic necrosis of a large part or all of the fragment follows. It is evident from the partial collapse which occurred in Case 3 that when necrosis of the body is diagnosed, the limb should be protected from weight-bearing for at least several months,—until union, revascularization, and transformation of necrotic area has been largely brought about. It seems probable that some of the bad results that have been reported in fracture of the neck of the astragalus, either united or ununited, have been due to overlooked aseptic necrosis of the body.

The etiology of the lesions dealt with up to this point has been clear. The röle of embolism in the production of both septic and aseptic bone necrosis is still imperfectly understood. Ritter, Winkebauer and Axhausen [11] have expressed the belief that in pyogenic osteomyelitis the extensive necrosis of bone is the result of septic embolism cutting off the blood supply of large areas at the onset of the process with subsequent invasion and infection of the infarcted area by bacteria from the embolus. This view is inconsistent with our knowledge of the blood supply of the cortex of the shaft of bones. The experiments of Johnson [12] showed that the periosteal vessels supply approximately the external half, while the internal half is supplied by the nutrient artery and metaphyseal vessels. Injury of either set of vessels results in necrosis of much of the bone which they supply. Now the dead bone in osteomyelitis is not limited to the region supplied by one or the other of these sets of vessels. While an embolus might account for extensive necrosis in the region supplied by the nutrient artery, this would be impossible in the regions supplied by the periosteal vessels since they are numerous and small. Usually the entire thickness of cortex of the involved region becomes necrotic. Also in primary and especially in recurrent osteomyelitis the infection may be observed, starting at one limited point and spreading more or less extensively to the rest of the bone.

Aseptic necrosis of bone, the result of proven thrombosis or embolism, is a condition that has been rarely reported in man. Axhausen [11] reported a case which was classed as multiple anaemic infarction of bones, but streptococcus longus anhemolyticus was cultured from the lesions. Consequently it is incorrect to speak of the condition as aseptic necrosis of bone.

Aseptic necrosis has been produced experimentally by injection of small aseptic emboli into the femoral artery. The infarcts formed in the ends of the shafts and rarely comprised a large part of the diaphysis, but epiphyseal necrosis was not produced. A marked osteoblastic reparative reaction developed about the necrotic bone which was rapidly replaced by new bone by the process of creeping substitution. The so called necrosing lesions of the center of ossification of certain epiphyses in children and the os lunatum in young adults have been variously attributed to injury to the blood vessels, vascular obstruction from embolism or thrombosis, and infection.

Thus Legg-Perthes’ disease sometimes follows reduction of congenital dislocation of the hip which points to vascular injury and the experiments of Nussbaum [13] show that cutting epiphyseal vessels results in necrosis followed by reorganization and deformity of the bony center. Phemister, Brunschwig, and Day [14] have cultured biopsied specimens from two cases each of Köhler^’s disease of the tarsal navicular bone, Legg-Perthes’ disease, and Kienbock’s disease of the os lunatum. They found that streptococci grew in cultures of four, and the indications are strong that this organism is the etiological factor in some cases. In one case of Köhler’s disease and in one of Legg-Perthes’ disease the cultures remained sterile, although the case of Köhler’s disease was associated with multiple osseous and lymph glandular tuberculosis. Histologically there was necrosis but no sign of tuberculosis in the navicular; consequently the case supports the theory of Axhausen that a caseous tuberculous embolus may be a cause of the necrosing lesions.

Histologically the majority of these lesions appear to have something more back of them than a simple bland embolus or injury cutting off the circulation’and producing aseptic necrosis. As previously stated, aseptic necrotic bone in continuity with living bone is gradually invaded and more or less completely replaced by new bone through the process of creeping substitution, unless it is too inaccessible and is broken down by traumatism. In these diseases there is a marked fibroblastic and fixed tissue phagocytic reaction and, in rare cases, an infiltrative reaction which result in absorption of necrotic bone without bony replacement by creeping substitution except in occasional instances. New bone formed from surviving osteogenic elements replaces more or less completely the absorptive tissues in the course of time.
