Comparison of chemical, electrical, and combined activation methods for in vitro matured porcine oocytes

  • Shuai Liu
  • Kuiqing Cui
  • Hong Li Li
  • Jun Ming Sun
  • Xing Rong Lu
  • Kai Yuan Shen
  • Qing You Liu
  • De Shun Shi
Article
First Online:
Received:
Accepted:

Abstract

Factors influencing porcine oocyte activation were systematically studied. This study included (1) the effect of ionomycin plus various chemical agents on activation, (2) comparison of different electrical activation parameters, (3) optimization of combined activation, and (4) evaluation of the optimized protocols. The results showed that (1) blastocyst rates of ionomycin (Ion) + 6-dimethylaminopurine (6-DMAP) (29.7 ± 1.1%), Ion + cytochalasin B (CB) + cycloheximide (CHX) (29.8 ± 1.2%), Ion + CB + 6-DMAP (30.4 ± 1.6%), and Ion + CB + CHX + 6-DMAP (30.2 ± 2.7%) were significantly higher than Ion + CHX (15.8 ± 1.5%, p < 0.05); (2) the parthenogenetic blastocyst formation of electrical activation was optimal when oocytes were activated by three direct current (DC) pulses of 1.00 kV cm−1 for 80 μs (39.5 ± 1.1%); (3) blastocyst rates of DC + CB + CHX (55.4 ± 1.2%) and DC + CB + 6-DMAP (50.4 ± 2.9%) were significantly higher than DC + 6-DMAP, DC + CB + CHX + 6-DMAP, electrical activation, and chemical activation alone (p < 0.05); and (4) approximately 84% of parthenogenetic blastocysts yielded by the optimized protocol were diploid, which was significantly higher than that of electrical activation blastocysts (40%). Using the optimized electrical and combined activation protocol, high blastocyst rates were generated by intracytoplasmic sperm injection (ICSI) (34.6 ± 1.1%), cytoplasmic microinjection (CI) (52.3 ± 2.2%), and handmade cloning (HMC) (31.2 ± 1.0%), respectively. This study concludes that the optimal activation protocol of in vitro matured porcine oocytes was combined activation with parameter as three DC pulses of 1.00 kV cm−1 for 80 μs plus CB and CHX treatment.

Keywords

Porcine oocytes Parthenogenetic activation Blastocyst development
This is a preview of subscription content, log in to check access.

Notes

Acknowledgments

This work was funded by the China 863 High-Tech Project (2011AA100607) and the National Natural Science Fund (NSFC 31260552).

Supplementary material

11626_2014_9819_MOESM1_ESM.tif (3.9 mb)
Additional Fig. 1 Blastocyst development after activated by ionomycin plus ethanol at 168 h (40×). (TIFF 4030 kb)

High resolution image (GIF 139 kb)

11626_2014_9819_MOESM2_ESM.tif (5.9 mb)
Additional Fig. 2 Blastocyst development after activated by different Ca2+ concentrations at 168 h (40×). (TIFF 6,037 kb)

High resolution image (GIF 183 kb)

11626_2014_9819_MOESM3_ESM.tif (2.4 mb)
Additional Fig. 3 Conventional karyotyping of parthenogenetic porcine blastocysts. (×1,000). (TIFF 2,471 kb)

High resolution image (GIF 10 kb)

11626_2014_9819_MOESM4_ESM.docx (16 kb)
ESM 4 (DOCX 16 kb)

References

  1. Alexander B, Coppola G, Di Berardino D, Rho G, St John E, Betts D, King W (2006) The effect of 6-dimethylaminopurine (6-DMAP) and cycloheximide (CHX) on the development and chromosomal complement of sheep parthenogenetic and nuclear transfer embryos. Mol Reprod Dev 73:20–30Google Scholar
  2. Betthauser J, Forsberg E, Augenstein M, Childs L, Eilertsen K, Enos J, Forsythe T, Golueke P, Jurgella G, Koppang R (2000) Production of cloned pigs from in vitro systems. Nat Biotechnol 18:1055–1059CrossRefPubMedGoogle Scholar
  3. Cao Z, Sui L, Li Y, Ji S, Zhang X, Zhang Y (2011) Effects of chemically defined medium on early development of porcine embryos derived from parthenogenetic activation and cloning. Zygote 1–8Google Scholar
  4. Chen Z, Liu Z, Huang J, Amano T, Li C, Cao S, Wu C, Liu B, Zhou L, Carter MG (2009) Birth of parthenote mice directly from parthenogenetic embryonic stem cells. Stem Cells 27:2136–2145CrossRefPubMedGoogle Scholar
  5. Collas P, Robl JM (1990) Factors affecting the efficiency of nuclear transplantation in the rabbit embryo. Biol Reprod 43:877–884CrossRefPubMedGoogle Scholar
  6. Collas P, Fissore R, Robl JM (1993) Preparation of nuclear transplant embryos by electroportation. Anal Biochem 208:1–9CrossRefPubMedGoogle Scholar
  7. Collas P, Chang T, Long C, Robl JM (1995) Inactivation of histone H1 kinase by Ca2+ in rabbit oocytes. Mol Reprod Dev 40:253–258CrossRefPubMedGoogle Scholar
  8. De La Fuente R, King WA (1998) Developmental consequences of karyokinesis without cytokinesis during the first mitotic cell cycle of bovine parthenotes. Biol Reprod 58:952–962CrossRefGoogle Scholar
  9. Du Y, Kragh PM, Zhang X, Purup S, Yang H, Bolund L, Vajta G (2005) High overall in vitro efficiency of porcine handmade cloning (HMC) combining partial zona digestion and oocyte trisection with sequential culture. Cloning Stem Cells 7:199–205CrossRefPubMedGoogle Scholar
  10. Fukui Y, Sawai K, Furudate M, Sato N, Iwazumi Y, Ohsaki K (1992) Parthenogenetic development of bovine oocytes treated with ethanol and cytochalasin B after in vitro maturation. Mol Reprod Dev 33:357–362CrossRefPubMedGoogle Scholar
  11. Grupen CG, Nagashima H, Nottle MB (1996) Role of epidermal growth factor and insulin-like growth factor-I on porcine oocyte maturation and embryonic development in vitro. Reprod Fertil Dev 9:571–575CrossRefGoogle Scholar
  12. Hai, T., Teng, F., Guo, R., Li, W. and Zhou, Q. (2014) One-step generation of knockout pigs by zygote injection of CRISPR/Cas system. Cell ResearchGoogle Scholar
  13. Holm P, Booth PJ, Callesen H (2003) Developmental kinetics of bovine nuclear transfer and parthenogenetic embryos. Cloning Stem Cells 5:133–142CrossRefPubMedGoogle Scholar
  14. Hosseini S, Hajian M, Moulavi F, Shahverdi A, Nasr-Esfahani M (2008) Optimized combined electrical–chemical parthenogenetic activation for in vitro matured bovine oocytes. Anim Reprod Sci 108:122–133CrossRefPubMedGoogle Scholar
  15. Kim YS, Lee SL, Ock SA, Balasubramanian S, Choe SY, Rho GJ (2005) Development of cloned pig embryos by nuclear transfer following different activation treatments. Mol Reprod Dev 70:308–313CrossRefPubMedGoogle Scholar
  16. Kumar D, Gopalakrishna R, Singh AP, Ranjan R, Pandey SK, Sarkhel BC (2014) Developmental potency of pre-implant parthenogenetic goat embryos: effect of activation protocols and culture media. In Vitro Cell Dev Biol Anim 50:1–6CrossRefPubMedGoogle Scholar
  17. Lee JW, Tian XC, Yang X (2004) Optimization of parthenogenetic activation protocol in porcine. Mol Reprod Dev 68:51–57CrossRefPubMedGoogle Scholar
  18. Li, C., Mizutani, E., Ono, T. and Wakayama, T. (2009) Production of normal mice from spermatozoa denatured with high alkali treatment before ICSI. Reproduction 137:779–792Google Scholar
  19. Lin J, Shi L, Zhang M, Yang H, Qin Y, Zhang J, Gong D, Zhang X, Li D, Li J (2011) Defects in trophoblast cell lineage account for the impaired in vivo development of cloned embryos generated by somatic nuclear transfer. Cell Stem Cell 8:371–375CrossRefPubMedGoogle Scholar
  20. Liu HB, Lv PR, Yang XG, Qin XE, Pi DY, Lu YQ, Lu KH, Lu SS, Li DS (2009) Fibroblasts from the new-born male testicle of Guangxi Bama mini-pig (Sus scrofa) can support nuclear transferred embryo development in vitro. Zygote 17:147–156CrossRefPubMedGoogle Scholar
  21. Machaty Z, Funahashi H, Day BN, Prather RS (1997) Developmental changes in the intracellular Ca2+ release mechanisms in porcine oocytes. Biol Reprod 56:921–930CrossRefPubMedGoogle Scholar
  22. Nagai T (1987) Parthenogenetic activation of cattle follicular oocytes in vitro with ethanol. Gamete Res 16:243–249CrossRefPubMedGoogle Scholar
  23. Ock S, Kwack D, Mohana Kumar B, Han J, Kim S, Rho G (2011) Effects of activation methods on DNA synthesis and development of parthenogenetic porcine embryos. Reprod Domest Anim 46:1082–1089CrossRefPubMedGoogle Scholar
  24. Ozil JP (1990) The parthenogenetic development of rabbit oocytes after repetitive pulsatile electrical stimulation. Development 109:117–127PubMedGoogle Scholar
  25. Presicce GA, Yang X (1994) Nuclear dynamics of parthenogenesis of bovine oocytes matured in vitro for 20 and 40 h. and activated with combined ethanol and cycloheximide treatment. Mol Reprod Dev 37:61–68CrossRefPubMedGoogle Scholar
  26. Ragina NP, Schlosser K, Knott JG, Senagore PK, Swiatek PJ, Chang EA, Fakhouri WD, Schutte BC, Kiupel M, Cibelli JB (2012) Downregulation of H19 improves the differentiation potential of mouse parthenogenetic embryonic stem cells. Stem Cells Dev 21:1134–1144CrossRefPubMedCentralPubMedGoogle Scholar
  27. Robl J, Collas P, Fissore R, Dobrinsky J, Chang D, Chassy B, Saunders J, Sowers A (1992) Electrically induced fusion and activation in nuclear transplant embryos. Guide Electroporation Electrofusion 535–551Google Scholar
  28. Shen P, Lee S, Liu B, Chu F, Wang C, Wu J, Lin H, Cheng W (2008) The effect of activation treatments on the development of reconstructed bovine oocytes. Anim Reprod Sci 106:1–12CrossRefPubMedGoogle Scholar
  29. Sun F, Hoyland J, Huang X, Mason W, Moor R (1992) A comparison of intracellular changes in porcine eggs after fertilization and electroactivation. Development 115:947PubMedGoogle Scholar
  30. Swann K, Ozil J-P (1994) Dynamics of the calcium signal that triggers mammalian egg activation. Int Rev Cytol 152:183–222CrossRefPubMedGoogle Scholar
  31. Thouas G. Korfiatis N, French A, Jones G, Trounson A (2001) Simplified technique for differential staining of inner cell mass and trophectoderm cells of mouse and bovine blastocysts. Reprod Biomed 3:25–29Google Scholar
  32. Tian J-H, Wu Z-H, Liu L, Cai Y, Zeng S-M, Zhu S-E, Liu G-S, Li Y, Wu C-X (2006) Effects of oocyte activation and sperm preparation on the development of porcine embryos derived from in vitro-matured oocytes and intracytoplasmic sperm injection. Theriogenology 66:439–448CrossRefPubMedGoogle Scholar
  33. Vitullo AD, Ozil J-P (1992) Repetitive calcium stimuli drive meiotic resumption and pronuclear development during mouse oocyte activation. Dev Biol 151:128–136CrossRefPubMedGoogle Scholar
  34. Wani N (2008) Chemical activation of in vitro matured dromedary camel (Camelus dromedarius) oocytes: optimization of protocols. Theriogenology 69:591–602CrossRefPubMedGoogle Scholar
  35. Watanabe M, Kurome M, Matsunari H. Nakano K, Umeyema K, Shiota A. Nakauchi H, Nagashima H (2011) The creation of transgenic pigs expressing human proteins using BAC-derived, full-length genes and intracytoplasmic sperm injection-mediated gene transfer. Transgenic Res 21(3):605–18Google Scholar
  36. Winger Q, De La Fuente R, King W, Armstrong D, Watson A (1997) Bovine parthenogenesis is characterized by abnormal chromosomal complements: implications for maternal and paternal co-dependence during early bovine development. Dev Genet 21:160–166CrossRefPubMedGoogle Scholar
  37. Yang F, Hao R, Kessler B, Brem G, Wolf E, Zakhartchenko V (2007) Rabbit somatic cell cloning: effects of donor cell type, histone acetylation status and chimeric embryo complementation. Reproduction 133:219–230CrossRefPubMedGoogle Scholar
  38. Yi YJ, Park CS (2005) Parthenogenetic development of porcine oocytes treated by ethanol, cycloheximide, cytochalasin B and 6-dimethylaminopurine. Anim Reprod Sci 86:297–304CrossRefPubMedGoogle Scholar
  39. Zhu J, Telfer EE, Fletcher J, Springbett A, Dobrinsky JR, De Sousa PA, Wilmut I (2002) Improvement of an electrical activation protocol for porcine oocytes. Biol Reprod 66:635–641CrossRefPubMedGoogle Scholar

Copyright information

© The Society for In Vitro Biology 2014

Authors and Affiliations

  • Shuai Liu
    • 1
  • Kuiqing Cui
    • 1
  • Hong Li Li
    • 1
  • Jun Ming Sun
    • 1
  • Xing Rong Lu
    • 1
  • Kai Yuan Shen
    • 1
  • Qing You Liu
    • 1
  • De Shun Shi
    • 1
  1. 1.State Key Laboratory for Conservation and Utilization of Subtropical Agro-bioresourcesGuangxi UniversityNanningChina
