Design and Ground Calibration of the Helioseismic and Magnetic Imager (HMI) Instrument on the Solar Dynamics Observatory (SDO)

  • J. Schou
  • P. H. Scherrer
  • R. I. Bush
  • R. Wachter
  • S. Couvidat
  • M. C. Rabello-Soares
  • R. S. Bogart
  • J. T. Hoeksema
  • Y. Liu
  • T. L. DuvallJr.
  • D. J. Akin
  • B. A. Allard
  • J. W. Miles
  • R. Rairden
  • R. A. Shine
  • T. D. Tarbell
  • A. M. Title
  • C. J. Wolfson
  • D. F. Elmore
  • A. A. Norton
  • S. Tomczyk
Open Access
THE SOLAR DYNAMICS OBSERVATORY

Abstract

The Helioseismic and Magnetic Imager (HMI) investigation (Solar Phys. doi:10.1007/s11207-011-9834-2, 2011) will study the solar interior using helioseismic techniques as well as the magnetic field near the solar surface. The HMI instrument is part of the Solar Dynamics Observatory (SDO) that was launched on 11 February 2010. The instrument is designed to measure the Doppler shift, intensity, and vector magnetic field at the solar photosphere using the 6173 Å Fe i absorption line. The instrument consists of a front-window filter, a telescope, a set of waveplates for polarimetry, an image-stabilization system, a blocking filter, a five-stage Lyot filter with one tunable element, two wide-field tunable Michelson interferometers, a pair of 40962 pixel cameras with independent shutters, and associated electronics. Each camera takes a full-disk image roughly every 3.75 seconds giving an overall cadence of 45 seconds for the Doppler, intensity, and line-of-sight magnetic-field measurements and a slower cadence for the full vector magnetic field. This article describes the design of the HMI instrument and provides an overview of the pre-launch calibration efforts. Overviews of the investigation, details of the calibrations, data handling, and the science analysis are provided in accompanying articles.

Keywords

Solar Dynamics Observatory Helioseismology, observations Instrumentation and data management Magnetic fields, photosphere

Supplementary material

11207_2011_9842_MOESM1_ESM.txt (149 kb)
(TXT 149 kB)
11207_2011_9842_MOESM2_ESM.txt (158 kb)
(TXT 157 kB)
11207_2011_9842_MOESM3_ESM.pdf (62 kb)
SDO/HMI Operational and Survival Heater Layout (PDF 62 kB)
11207_2011_9842_MOESM4_ESM.pdf (855 kb)
SDO/HMI Sensor Locations (PDF 854 kB)

References

  1. Couvidat, S., Schou, J., Shine, R.A., Bush, R.I., Miles, J.W., Scherrer, P.H., Rairden, R.L.: 2011, Wavelength dependence of the Helioseismic and Magnetic Imager (HMI) instrument onboard the Solar Dynamics Observatory (SDO). Solar Phys. doi:10.1007/s11207-011-9723-8.
  2. Lemen, J.R., Duncan, D.W., Edwards, C.G., Friedlaender, F.M., Jurcevich, B.K., Morrison, M.D., Springer, L.A., Stern, R.A., Wuelser, J., Bruner, M.E., Catura, R.C.: 2004, The solar X-ray imager for GOES. In: Fineschi, S., Gummin, M.A. (eds.) SPIE 5171, 65 – 76. doi:10.1117/12.507566. CrossRefGoogle Scholar
  3. Lemen, J.R., Title, A.M., Akin, D.J., Boerner, P.F., Chou, C., Drake, J.F., Duncan, D.W., Edwards, C.G., Friedlaender, F.M., Heyman, G.F., Hurlburt, N.E., Katz, N.L., Kushner, G.D., Levay, M., Lindgren, R.W., Mathur, D.P., McFeaters, E.L., Mitchell, S., Rehse, R.A., Schrijver, C.J., Springer, L.A., Stern, R.A., Tarbell, T.D., Wuelser, J.P., Wolfson, C.J., Yanari, C., Bookbinder, J.A., Cheimets, P.N., Caldwell, D., Deluca, E.E., Gates, R., Golub, L., Park, S., Podgorski, W.A., Bush, R.I., Scherrer, P.H., Gummin, M.A., Smith, P., Auker, G., Jerram, P., Pool, P., Soufli, R., Windt, D.L., Beardsley, S., Clapp, M., Lang, J., Waltham, N.: 2011, The Atmospheric Imaging Assembly (AIA) on the Solar Dynamics Observatory (SDO). Solar Phys. doi:10.1007/s11207-011-9776-8.
  4. Norton, A.A., Graham, J.P., Ulrich, R.K., Schou, J., Tomczyk, S., Liu, Y., Lites, B.W., López Ariste, A., Bush, R.I., Socas-Navarro, H., Scherrer, P.H.: 2006, Spectral line selection for HMI: A comparison of Fe i 6173 Å and Ni i 6768 Å. Solar Phys. 239, 69 – 91. doi:10.1007/s11207-006-0279-y. ADSCrossRefGoogle Scholar
  5. Scherrer, P.H., Bogart, R.S., Bush, R.I., Hoeksema, J.T., Kosovichev, A.G., Schou, J., Rosenberg, W., Springer, L., Tarbell, T.D., Title, A., Wolfson, C.J., Zayer, I., MDI Engineering Team: 1995, The solar oscillations investigation – Michelson Doppler Imager. Solar Phys. 162, 129 – 188. doi:10.1007/BF00733429. ADSCrossRefGoogle Scholar
  6. Scherrer, P.H., Schou, J., Bush, R.I., Kosovichev, A.G., Bogart, R.S., Hoeksema, J.T., Liu, Y., Duvall, T.L., Title, A.M., Tomczyk, S., HMI Science Team: 2011, The helioseismic and magnetic imager investigation. Solar Phys. doi:10.1007/s11207-011-9834-2.
  7. Schou, J., Borrero, J.M., Norton, A.A., Tomczyk, S., Elmore, D., Card, G.L.: 2010, Polarization calibration of the Helioseismic and Magnetic Imager (HMI) onboard the Solar Dynamics Observatory (SDO). Solar Phys. doi:10.1007/s11207-010-9639-8.
  8. Wachter, R., Schou, J.: 2009, Inferring small-scale flatfields from solar rotation. Solar Phys. 258, 331 – 341. doi:10.1007/s11207-009-9406-x. ADSCrossRefGoogle Scholar
  9. Wachter, R., Schou, J., Rabello-Soares, M.C., Miles, J.W., Duvall, T.L., Bush, R.I.: 2011, Image quality of the Helioseismic and Magnetic Imager (HMI) onboard the Solar Dynamics Observatory (SDO). Solar Phys. doi:10.1007/s11207-011-9709-6.
