Fabrication of three-dimensional hemispherical structures using photolithography
- 233 Downloads
- 5 Citations
Abstract
A photolithography technique using SU-8 and PDMS was developed to fabricate three-dimensional hemispherical structures. This technique utilized a mask-aligner and normal binary coded photomasks to generate hemispherical pits on SU-8, followed by PDMS molding to obtain an array of dome-shaped structures. Using this technique, a microfluidic device was fabricated with a patterning area that consisted of an array of 5 μm wells and dome-shaped structures with 10 μm diameter and 6 μm height. Encoded microbeads, 6 μm in size, were immobilized and patterned in the microfluidic device under flow conditions and a DNA hybridization experiment was performed to demonstrate the incorporation of encoded beads that would enable a high level of multiplexing in bioassays.
Keywords
3D structures Microfluidics Photolithography SU-8 Soft lithographyNotes
Acknowledgments
We would like to acknowledge the funding of this research work by the National University of Singapore, WBS no: R-397-000-027-112.
Supplementary material
References
- Daschner W, Larsson M, Lee SH (1995) Fabrication of monolithic diffractive optical elements by the use of e-beam direct write on an analog resist and a single chemically assisted ion-beam-etching step. Appl Optics 34:2534–2539CrossRefGoogle Scholar
- Dutta RK, van Kan JA, Bettiol AA et al (2007) Polymer microlens replication by nanoimprint lithography using proton beam-fabricated Ni stamp. Nucl Instr Meth in Phys Res B 260:464–467CrossRefGoogle Scholar
- Galas JC, Belier B, Aassime A et al (2004) Fabrication of three-dimensional microstructures using standard ultraviolet and electron-beam lithography. J Vac Sci Technol B 22:1160–1162CrossRefGoogle Scholar
- Geissler M, Xia Y (2004) Patterning: principles and some new developments. Adv Mat 16:1249–1269CrossRefGoogle Scholar
- Henke W, Hoppe W, Quenzer et al (1995) Simulation-assisted design of processes for gray-tone lithography. Microelectron Eng 27:267–270CrossRefGoogle Scholar
- Kolarova H, Hengerer B (1996) Preparation of magnetic oligo(dT) particles. BioTechniques 20:196–198Google Scholar
- Lim CT, Zhang Y (2007) Bead-based microfluidic immunoassays: the next generation. Biosens Bioelectron 22:1197–1204CrossRefGoogle Scholar
- Oppliger Y, Sixt P, Stauffer JM et al (1994) One-step 3D shaping using a gray-tone mask for optical and microelectronic applications. Microelectron Eng 23:449–454CrossRefGoogle Scholar
- Schwartz B, Robbins H (1976) Chemical etching of silicon. J Electrochem Soc 123:1903–1909CrossRefGoogle Scholar
