Primary retroperitoneal cystic mucinous borderline tumour mimicking an ovarian neoplasm: a case report and literature review
- 176 Downloads
- 1 Citations
Abstract
Ovarian-type mucinous tumours occur very rarely in the retroperitoneum. We present a case of primary retroperitoneal mucinous tumour of borderline malignancy in a 58-year-old woman, detected as an incidental finding. The patient presented with acute renal failure, investigation for which revealed a complex pelvic mass initially thought to be in the right adnexa and consistent with an ovarian neoplasm. Surgical findings revealed a 130-mm, right-sided non-communicating retroperitoneal pelvic mass, posterior to the appendix, which was completely resected. Both ovaries were normal. Macroscopically, it was a multi-loculated cystic structure with a smooth external surface containing clear and mucinous fluid. Microscopic examination showed a mucinous tumour of borderline malignancy. The literature contains approximately nine other cases of primary mucinous retroperitoneal tumour of borderline malignancy. These cases have occurred in women aged 36–60 years. Most patients were asymptomatic and the mass was detected as an incidental finding. The patients have been followed up for up to 6 to 18 months and, to date, none have recurred. There are limitations to pre-operative radiological imaging. A definitive diagnosis can only be made after complete surgical excision and histological examination, having excluded retroperitoneal involvement by mucinous tumours from sites such the ovaries, bowel, appendix and pancreas.
Keywords
Retroperitoneum Primary Cystic mucinous borderline tumoursIntroduction
Primary cystic mucinous tumours of the retroperitoneum are rare tumours and have been reported in women with normal ovaries [1, 2]. The histological appearances of these tumours are similar to ovarian mucinous tumours, spanning the entire spectrum from benign, borderline and malignant. Immunohistochemical and molecular studies have also shown similarities to their ovarian counterparts [1]. The precise aetiology of these neoplasms is uncertain and various theories have been proposed [3]. In the majority of instances, preoperative diagnosis is not possible, as radiological findings are not able to distinguish the exact nature and origin of these lesions [4]. A definitive diagnosis can only be made after complete surgical excision and histological examination, having excluded retroperitoneal involvement by mucinous tumours from sites such the ovaries, bowel, appendix and pancreas.
Due to the rarity of these tumours and the limited information available about the biological behaviour, the optimal treatment options, survival and exact prognosis are uncertain.
We report an additional case of a primary retroperitoneal mucinous tumour of borderline malignancy in a 58-year-old woman with normal ovaries. Also, cystic mucinous tumours of the retroperitoneum in the available literature have been reviewed with regards to clinical presentation, diagnostic histological appearances, treatment options and survival data.
Case history
A 58-year-old lady was incidentally found to have a large abdominal mass, on investigation for acute renal failure and dyspnoea. Imaging revealed a complex 160×140×130-mm mass in the right adnexa, intimately related to the small and large bowel superiorly, initially thought to be consistent with an ovarian neoplasm. It was separate from the kidney and pancreas. The liver, spleen, pancreas, urinary bladder and uterus appeared normal. The serum levels of CEA, CA 125 and CA 19-9 were within normal limits.
At laparotomy, a non-communicating mass was found, which was confirmed to be a right-sided retroperitoneal pelvic mass with small bowel adhesions and the appendix draped over. Posteriorly, this was attached to the psoas major muscle. The uterus, both ovaries and the fallopian tubes were macroscopically normal, as were the peritoneum, intestines and omentum. During surgical intervention, on mobilisation, the mass ruptured, with some spillage of mucinous and clear material. The mass was completely resected, the appendix was also removed and the uterus and ovaries were left intact. Post-operatively, chemotherapy was not given. She made a reasonably good recovery and has been followed up until now for a period of 12 months without evidence of recurrence.
Pathological findings
Internal surface of the cyst wall; multi-loculated mass with multiple thin-walled cystic structures and a solid nodule (arrow)
Microscopy: cyst lining comprising intestinal-type columnar mucous-secreting epithelium. The tumour displays a complex glandular architecture without stromal invasion (a–d). Stratification of the epithelium with a thickness of two to three cell layers (c, d). High-power view showing mild to moderate nuclear atypia with mitoses (d). Immunohistochemistry: the tumour exhibits diffuse strong expression of CK 7 (e) and patchy strong expression of CK 20 (f)
Discussion
Primary cystic mucinous tumours of the retroperitoneum are rare tumours and cases with borderline pathology are even rarer. Approximately 33 cases of cystadenomas, 35 cases of cystadenocarcinoma and nine cases of borderline malignancy have been published in the literature to date. These tumours have been described exclusively in females; however, very rarely, they have been described in male patients [4, 5].
The histogenesis of these tumours is not clear and several theories have been proposed. Most authors suggest mucinous metaplasia in pre-existing mesothelium-lined cysts, which are more common in this location. Invaginations of peritoneum/mesothelium result in these inclusion cysts that undergo mucinous metaplasia, thus, resulting in a mucinous cystadenoma [1, 3, 6]. Some have suggested that clusters of coelomic epithelial cells could be deposited along the route of ovarian descent and, by proliferation or metaplastic differentiation, develop into these cystic tumours [7, 8]. Other theories include an origin from ectopic ovarian tissue and teratomas [9].
The differential diagnosis includes metastatic mucinous tumours, from sites such as ovaries, the intestines, including the appendix and pancreas [9]. Other neoplastic lesions in this site include cystic lymphangioma, cystic teratoma, cystic mesothelioma, mullerian cyst, epidermoid cyst and tailgut cyst [2].
The three main categories of cystic mucinous tumours of the retroperitoneum are reviewed with regards to clinical presentation and diagnostic histological appearances, together with treatment options and survival data.
Mucinous cystadenomas
Patients with mucinous cystadenomas presented at an age ranging from 19 to 67 years. Macroscopically, these tumours are usually large, ranging from 60 to 300 mm in diameter [3, 10]. Microscopic examination shows mucin-filled, thin-walled uni- or multi-loculated cysts lined by a single layer of columnar mucinous epithelial cells with basal nuclei. Cytological atypia is not seen [2, 11, 12]. It is noted that tumour excision has been the main treatment modality. These patients have been followed up for a period ranging from 6 months to 18 months with no evidence of recurrence [3, 11, 12].
Mucinous cystadenocarcinomas
These patients have presented at an age ranging from 17 years to 86 years. The maximum diameters of these tumours varied from 60 to 240 mm [13, 14]. Microscopic examination reveals varying degrees of differentiation from areas of benign mucinous columnar epithelium through borderline areas and frankly malignant adenocarcinomatous foci [1, 4]. The malignant foci show cysts lined by papillae with atypical stratified mucinous epithelium and occasional mitoses. Also seen are islands of closely packed and moderately well formed glands with focal areas of cribriform patterns lined by cells with enlarged pleomorphic nuclei and prominent nucleoli. Focal central necrosis and stromal invasion was also exhibited [6, 15]. Extra-capsular extension was not seen in most cases [1, 14]. Mural nodules composed of pleomorphic sarcomatoid cells with numerous mitoses have been reported in rare cases and were associated with an aggressive clinical course [14]. Patients were treated with tumour excision alone [9, 15] or with subsequent combined total hysterectomy and bilateral salpingo-oophorectomy [1, 6]. Post-operative chemotherapy was offered to some of these patents independent of the surgical modality of treatment [1, 4, 9]. The follow up period ranged from 6 months to 6 years after surgery. In most cases, the prognosis seems to be good when additional surgery was performed and patients have remained free of recurrence or metastasis [1, 6, 13]. The development of tumour recurrences and metastasis have been known to occur when simple tumour excision was performed with or without chemotherapy [9, 14].
Cystic mucinous borderline tumours
Primary retroperitoneal cystic mucinous borderline tumours; a review of the available literature
|
| Author | Age (years) | Size (mm) | Diagnosis (terminology used) | Treatment | Follow up period and outcome |
|---|---|---|---|---|---|---|
| 1 | Nagata et al. 1987 | 41 | 120 | Mucinous cystadenoma of low-grade malignancy | Tumour excision | NA |
| 2 | Banerjee and Gough 1987 | 47 | 35 | Borderline mucinous cystadenocarcinoma | Tumour excision | Not described |
| 3 | Motoyama et al. 1994 | 63 | 60 | Borderline mucinous tumour | Tumour excision | Not described |
| 4 | Pearl et al. 1996 | 33 | ND | Primary retroperitoneal mucinous cystadenocarcinoma of low malignant potential | Tumour excision | 10 month NE recurrence |
| 5 | Papadogiannakis et al. 1997 | 33 | 130 | Ovarian-like mucinous tumour of low malignant potential | Tumour excision | 12 month NED |
| 6 | Chen et al. 1998 | 48 | 150 | Mucinous cystadenoma with borderline malignancy | Tumour excision | 8 month NED |
| 7 | Gutsu et al. 2003 | 41 | 210 | Mucinous cystadenoma of borderline type | Tumour excision | 18 month NED |
| 8 | Matsubara et al. 2005 | 36 | 120 | Primary retroperitoneal mucinous cystic tumour of borderline malignancy | Tumour excision appendectomy myomectomy | 6 months NED |
| 9 | Bakker et al. 2007 | 45 | 160 | Mucinous cystadenoma with foci of borderline malignancy | Tumour excision | 12 month NED |
| 10 | Present case 2008 | 58 | 160 | Primary retroperitoneal cystic mucinous borderline tumour | Tumour excision and appendectomy | 12 month NED |
The majority of patients in the three groups of mucinous tumours (benign, borderline and malignant) have been asymptomatic, some presented with vague symptoms of abdominal fullness and, rarely, others presented as an abdominal mass. Most reports have included information regarding the uterus, tubes and ovaries being normal [3, 4, 12, 13].
There are limitations in the role of pre-operative radiological imaging; a final diagnosis can only be made after histological examination and the exclusion of a mucinous tumour elsewhere in the abdomen by careful clinical and radiological examination.
Regarding treatment, there is agreement on complete surgical excision of the lesion. The role of additional surgery and how extensive it should be is not clear when the uterus and ovaries are macroscopically normal.
For malignant lesions, some authors have recommended more aggressive treatment. Hysterectomy with bilateral salpingo-oophorectomy performed simultaneously or later may be necessary to improve survival [6, 9]. Omentectomy and pelvic/para-aortic lymph node resection were also performed in a few cases [1, 6]. However, Kessler et al. suggest that an extensive surgical procedure with serious consequences cannot be justified when the uterus and ovaries are macroscopically normal, and also when follow up in the majority of the reported cases is deficient. The only reason for this procedure to be performed is in post-menopausal women or patients who have completed child-bearing [23]. More conservative surgery has been proposed by Law et al., who advocate for laparoscopic excision of the tumour and complete evaluation of the abdominal and pelvic organs, sparing fertility in these women [24]. Adjuvant chemotherapy is not a standard treatment and its effectiveness is uncertain [13]. It is suggested that it is beneficial in cases with spillage of cyst fluid associated with tumour rupture during surgical intervention [1] or when the invasion of adjacent structures is macroscopically evident [4].
In borderline lesions, there is no clear evidence about the additional removal of the uterus, tubes and ovaries or about post-operative chemotherapy. The literature suggests that prognosis in these cases is good and complete surgical excision appears to be curative (Table 1). The prevention of cyst fluid spillage during surgical manipulation is important [20].
Bearing in mind the differential diagnosis of primary retroperitoneal mucinous tumours, it will allow appropriate pre-operative planning, enabling the surgeon to consider an extra-peritoneal surgical approach and remove the cyst in toto (without any spillage) with intact peritoneum possible.
Biological behaviour can be better defined and survival data can be collected as more cases are reported. Our case is another addition to the literature on this rare tumour with borderline pathology, which was treated by tumour excision without additional therapy, and has been disease-free in the 12 months of follow up, until now.
From the available evidence, we feel that the experience of retroperitoneal mucinous tumours remains limited and minimal data exists to define the appropriate management. In view of the rarity and possible malignant potential of these lesions, we are of the opinion that an early diagnosis and treatment with multi-disciplinary review is essential. Further follow up should be individualised and is dependent on factors like peri-operative spillage and tumour load.
References
- 1.Tenti P, Carnevali L, Tateo S, Durola R (1994) Primary mucinous cystoadenocarcinoma of the retroperitoneum: two cases. Gynecol Oncol 55(2):308–312PubMedCrossRefGoogle Scholar
- 2.Yang DM, Jung DH, Kim H, Kang JH, Kim SH, Kim JH, Hwang HY (2004) Retroperitoneal cystic masses: CT, clinical, and pathologic findings and literature review. Radiographics 24:1353–1365PubMedCrossRefGoogle Scholar
- 3.Pennell TC, Gusdon JP Jr (1989) Retroperitoneal mucinous cystadenoma. Am J Obstet Gynecol 160(5 Pt 1):1229–1331PubMedGoogle Scholar
- 4.de Leon DC, Pérez-Montiel D, Chanona-Vilchis J, Dueñas-González A, Villavicencio-Valencia V, Zavala-Casas G (2007) Primary retroperitoneal mucinous cystadenocarcinoma: report of two cases. World J Surg Oncol 5:5PubMedCrossRefGoogle Scholar
- 5.Thamboo TP, Sim R, Tan S-Y, Yap W-M (2006) Primary retroperitoneal mucinous cystadenocarcinoma in a male patient. J Clin Pathol 59:655–657PubMedCrossRefGoogle Scholar
- 6.Lee IW, Ching KC, Pang M, Ho TH (1996) Two cases of primary retroperitoneal mucinous cystadenocarcinoma. Gynecol Oncol 63:145–150PubMedCrossRefGoogle Scholar
- 7.Pearl ML, Valea F, Chumas J, Chalas E (1996) Primary retroperitoneal mucinous cystadenocarcinoma of low malignant potential: a case report and literature review. Gynecol Oncol 61(1):150–152PubMedCrossRefGoogle Scholar
- 8.Papadogiannakis N, Gad A, Ehliar B (1997) Primary retroperitoneal mucinous tumor of low malignant potential: histogenetic aspects and review of the literature. APMiS 105(6):483–486PubMedGoogle Scholar
- 9.Gotoh K, Konaga E, Arata A, Takeuchi H, Mano S (1992) A case of primary retroperitoneal mucinous cystadenocarcinoma. Acta Med Okayama 46(1):49–52PubMedGoogle Scholar
- 10.Bortolozzi G, Grasso A, Zasso B (1995) Mucinous cystadenoma of the retroperitoneum. A case report and review. Eur J Gynaecol Oncol 16(1):65–68PubMedGoogle Scholar
- 11.Min BW, Kim JM, Um JW, Lee ES, Son GS, Kim SJ, Moon HY (2004) The first case of primary retroperitoneal mucinous cystadenoma in Korea: a case report. Korean J Intern Med 19(4):282–284PubMedGoogle Scholar
- 12.Balat O, Aydin A, Sirikci A, Kutlar I, Aksoy F (2001) Huge primary mucinous cystadenoma of the retroperitoneum mimicking a left ovarian tumor. Eur J Gynaecol Oncol 22(6):454–455PubMedGoogle Scholar
- 13.Uematsu T, Kitamura H, Iwase M, Tomono H, Nakamura M, Yamashita K, Ogura H (2000) Ruptured retroperitoneal mucinous cystadenocarcinoma with synchronous gastric carcinoma and a long postoperative survival: case report. J Surg Oncol 73(1):26–30PubMedCrossRefGoogle Scholar
- 14.Mikami M, Tei C, Takehara K, Komiyama S, Suzuki A, Hirose T (2003) Retroperitoneal primary mucinous adenocarcinoma with a mural nodule of anaplastic tumor: a case report and literature review. Int J Gynecol Pathol 22(2):205–208PubMedCrossRefGoogle Scholar
- 15.Jørgensen LJ, Vibits H (1991) Primary retroperitoneal mucinous cystadenocarcinoma. A case report and review of the literature. APMIS 99(11):1055–1057PubMedCrossRefGoogle Scholar
- 16.Motoyama T, Chida T, Fujiwara T, Watanabe H (1994) Mucinous cystic tumor of the retroperitoneum. A report of two cases. Acta Cytol 38(2):261–266PubMedGoogle Scholar
- 17.Nagata J, Yamauchi M, Terabe K, Watanabe T, Ichihara H, Takagi H, Nakashima N (1987) A case of retroperitoneal mucinous cystadenoma of borderline malignancy. Nippon Geka Gakkai Zasshi 88(4):489–492PubMedGoogle Scholar
- 18.Matsubara M, Shiozawa T, Tachibana R, Hondo T, Osasda K, Kawaguchi K, Kimura K, Konishi I (2005) Primary retroperitoneal mucinous cystadenoma of borderline malignancy: a case report and review of the literature. Int J Gynecol Pathol 24(3):218–223PubMedCrossRefGoogle Scholar
- 19.Gutsu E, Mishin I, Gagauz I (2003) Primary retroperitoneal mucinous cystadenoma. A case report and brief review of the literature. Zentralbl Chir 128(8):691–693PubMedCrossRefGoogle Scholar
- 20.Chen JS, Lee WJ, Chang YJ, Wu MZ, Chiu KM (1998) Laparoscopic resection of a primary retroperitoneal mucinous cystadenoma: report of a case. Surg Today 28(3):343–345PubMedCrossRefGoogle Scholar
- 21.Banerjee R, Gough J (1988) Cystic mucinous tumours of the mesentery and retroperitoneum: report of three cases. Histopathology 12:527–532PubMedCrossRefGoogle Scholar
- 22.Bakker RF, Stoot JH, Blok P, Merkus JW (2007) Primary retroperitoneal mucinous cystadenoma with sarcoma-like mural nodule: a case report and review of the literature. Virchows Arch 451(4):853–857PubMedCrossRefGoogle Scholar
- 23.Kessler TM, Kessler W, Neuweiler J, Nachbur BH (2002) Treatment of a case of primary retroperitoneal mucinous cystadenocarcinoma: is adjuvant hysterectomy and bilateral salpingo-oophorectomy justified? Am J Obstet Gynecol 187:227–232PubMedCrossRefGoogle Scholar
- 24.Law KS, Chang TM, Tung JN (2006) Fertility-sparing treatment of a primary retroperitoneal mucinous cystadenocarcinoma. BJOG 113:612–614PubMedCrossRefGoogle Scholar
