, Volume 25, Issue 4, pp 637–646 | Cite as

Climate controls act at different scales on the seasonal pattern of Quercus ilex L. stem radial increments in NE Spain

  • Emilia GutiérrezEmail author
  • Filipe Campelo
  • J. Julio Camarero
  • Montserrat Ribas
  • Elena Muntán
  • Cristina Nabais
  • Helena Freitas
Original Paper


Long-term data on radial increment dynamics in Mediterranean species may identify which climatic variables are the main constraints for radial growth and at which temporal scales they act. To this end, we examined stem radial fluctuations in Quercus ilex L., the dominant evergreen oak species in the Western Mediterranean Basin, over a period of 11 years (1994–2004) at a coastal site in north-eastern Spain. We used manual band dendrometers to record girth changes in trees on north- and south-facing slopes. Annual increments measured by dendrometers showed good agreement with annual tree-ring width. North-facing trees showed a lower long-term cumulative radial increment than south-facing trees. The seasonal radial increment pattern of Q. ilex was bimodal, being characterized by a greater increase in May and a lesser, more variable increase peak in September. Both phases corresponded to warm and moist climatic conditions, whereas radial increase of stems stopped in winter and occasionally in summer. Considering the whole year, mean maximum air temperature was the main factor positively affecting radial increment of Q. ilex from short- (5 days) to- long (30 days) time scales, whereas the accumulated precipitation exerted a similar effect at longer (30 days) scales, but only on south-facing trees. In summer, all trees were positively correlated with precipitation at long-time scales (30 days); however, only stem increment of south-facing trees showed a significant relation to the temperature at short-time scales (10 days). We confirmed the dominant role of temperature as the major constraint on radial increment at short time scales, despite most previous studies were mostly biased towards precipitation effects at monthly scales.


Band dendrometer Drought Mediterranean climate Bimodal growth Holm oak



This study was initiated thanks to the Spanish project (Ref. FOR91-0689) directed by Dr. Gabriel Montserrat. It was also partially funded by the EU project FORMAT (Ref. ENV4-CT97-0641). We thank the Unidad de Sanidad Forestal (Gob. Aragón) and the Parc Nat. Garraf (Dip. Barcelona) for their support. We are very grateful to A. Bernat and M. Abril (Dept. d’Ecologia, Univ. Barcelona) who helped during fieldwork. We thank Robin Rycroft for revising English, and two anonymous referees whose criticisms and comments helped us to improve the manuscript. FC was funded by FCT (Portuguese Ministry for Science and Technology) through a PhD fellowship (SFRH/BD/10677/2002). JJC acknowledges the financial and collaborative support of project CGL2008-04847-C02-01/BOS (CICyT, FEDER,) ARAID and Globimed.

Conflict of interest

The authors declare that we have no conflict of interest.


  1. Barbero M, Loisel R, Quézel P (1992) Biogeography, ecology and history of Mediterranean Quercus ilex ecosystems. Vegetatio 99–100:19–34CrossRefGoogle Scholar
  2. Bouriaud O, Leban JM, Bert D, Deleuze C (2005) Intra-annual variations in climate influence growth and wood density of Norway spruce. Tree Physiol 25:651–660PubMedGoogle Scholar
  3. Camarero JJ, Guerrero-Campo J, Gutiérrez E (1998) Tree-ring growth and structure of Pinus uncinata and Pinus sylvestris in the Central Spanish Pyrenees. Arctic Alpine Res 30:1–10CrossRefGoogle Scholar
  4. Campelo F, Gutiérrez E, Ribas M, Nabais C, Freitas H (2007) Relationships between climate and double rings in Quercus ilex from northeast Spain. Can J For Res 37:1915–1923CrossRefGoogle Scholar
  5. Campelo F, Nabais C, García-González I, Cherubini P, Gutiérrez E, Freitas H (2009) Dendrochronology of Quercus ilex L. and its potential use for climate reconstruction in the Mediterranean region. Can J For Res 39:2486–2493. doi: 10.1139/X09-163 CrossRefGoogle Scholar
  6. Cartan-Son M, Floret C, Galan MJ, Grandjanny M, Le Floc’h E, Maistre M, Perret P, Romane F (1992) Factors affecting radial growth of Quercus ilex L. in a coppice stand in southern France. Vegetatio 99–100:61–68CrossRefGoogle Scholar
  7. Castro-Díez P, Montserrat-Martí G (1998) Phenological pattern of fifteen Mediterranean phanaerophytes from Quercus ilex communities of NE Spain. Plant Ecol 139:103–112CrossRefGoogle Scholar
  8. Cherubini P, Gartner BL, Tognetti R, Bräker OU, Schoch W, Innes JL (2003) Identification, measurement and interpretation of tree rings in woody species from mediterranean climates. Biol Rev 78:119–148PubMedCrossRefGoogle Scholar
  9. Corcuera L, Camarero JJ, Gil-Pelegrin E (2004) Effects of a severe drought on Quercus ilex radial growth and xylem anatomy. Trees 18:83–92Google Scholar
  10. Corcuera L, Morales F, Abadia A, Gil-Pelegrin E (2005) Seasonal changes in photosynthesis and photoprotection in a Quercus ilex subsp. ballota woodland located in its upper altitudinal extreme in the Iberian Peninsula. Tree Physiol 25:599–608PubMedGoogle Scholar
  11. Cotillas M, Sabaté S, Gracia C, Espelta JM (2009) Growth response of mixed mediterranean oak coppices to rainfall reduction. Could selective thinning have any influence on it? For Ecol Manag 258:1677–1683CrossRefGoogle Scholar
  12. Daudet FA, Ameglio T, Cochard H, Archilla O, Lacointe A (2005) Experimental analysis of the role of water and carbon in tree stem diameter variations. J Exp Bot 56:135–144PubMedGoogle Scholar
  13. Deslauriers A, Morin H, Urbinati C, Carrer M (2003) Daily weather response of balsam fir (Abies balsamea (L.) Mill.) stem radius increment from dendrometer analysis in the boreal forests of Quebec (Canada). Trees 17:477–484Google Scholar
  14. Deslauriers A, Rossi S, Anfodillo T (2007) Dendrometer and intra-annual tree growth: what kind of information can be inferred? Dendrochronologia 25:113–124CrossRefGoogle Scholar
  15. Drew DM, Downes GM (2009) The use of precision dendrometers in research on daily stem size and wood property variation: a review. Dendrochronologia 27:159–172CrossRefGoogle Scholar
  16. Dünisch O, Bauch J, Gasparotto L (2002) Formation of increment zones and intraannual growth dynamics in the xylem of Swietenia macrophylla, Carapa guianensis, and Cedrela odorata (Meliaceae). IAWA Bull 23:101–119Google Scholar
  17. Filella I, Llusìa J, Piñol J, Peñuelas J (1998) Leaf gas exchange and fluorescence of Phillyrea latifolia and Quercus ilex samplings in severe drought and high temperature conditions. Environ Exp Bot 39:213–220CrossRefGoogle Scholar
  18. Folch R (1986) La vegetació dels Països Catalans. Ed. Ketres, BarcelonaGoogle Scholar
  19. Fraser DA (1962) Tree growth in relation to soil moisture. In: Kozlowski TT (ed) Tree growth. The Ronald Press, New York, pp 183–204Google Scholar
  20. Fritts HC (1976) Tree rings and climate. Academic Press, New YorkGoogle Scholar
  21. Gea-Izquierdo G, Martín-Benito D, Cherubini P, Cañellas I (2009) Climate-growth variability in Quercus ilex L. west Iberian open woodlands of different stand density. Ann For Sci 66:802. doi: 10.1051/forest/2009080 CrossRefGoogle Scholar
  22. Gratani L (1996) Leaf and shoot growth dynamics of Quercus ilex L. Acta Oecol 17:17–27Google Scholar
  23. Gratani L (2000) Leaf temperature effects on gas exchange in Quercus ilex L. growing under field conditions. Plant Biosyst 134:19–24CrossRefGoogle Scholar
  24. Gratani L, Pesoli P, Crescente MF, Aichner K, Larcher W (2000) Photosynthesis as a temperature indicator in Quercus ilex L. Glob Planet Change 24:153–163CrossRefGoogle Scholar
  25. Gratani L, Varone L, Catoni R (2008) Relationship between net photosynthesis and leaf respiration in Mediterranean evergreen species. Photosynthetica 46:567–573CrossRefGoogle Scholar
  26. IPCC (2007) Climate change 2007: impacts, adaptation and vulnerability. Cambridge University Press, CambridgeGoogle Scholar
  27. Keeland BD, Sharitz RR (1993) Accuracy of tree growth measurements using dendrometer bands. Can J For Res 23:2454–2457CrossRefGoogle Scholar
  28. Larcher W (2000) Temperature stress and survival ability of Mediterranean sclerophyllous plants. Plant Biosyst 134:279–295CrossRefGoogle Scholar
  29. Liphschitz N, Lev-Yadun S (1986) Cambial activity of evergreen and seasonal dimorphics around the Mediterranean. IAWA Bull 7:145–153Google Scholar
  30. Littell RC, Milliken GA, Stroup WW, Wolfinger RD, Schabenberger O (2006) SAS system for mixed models. SAS Institute, CaryGoogle Scholar
  31. Llorens L, Peñuelas J, Filella I (2003) Diurnal and seasonal variations in the photosynthetic performance and water relations of two co-occurring Mediterranean shrubs, Erica multiflora and Globularia alypum. Physiol Plant 8:84–95CrossRefGoogle Scholar
  32. Mäkinen H, Seo J-W, Nöjd P, Schmitt U, Jalkanen R (2008) Seasonal dynamics of wood formation: a comparison between pinning, microcoring and dendrometer measurements. Eur J For Res 127:235–245Google Scholar
  33. Mitrakos K (1980) A theory for Mediterranean plant life. Acta Oecol 1:245–252Google Scholar
  34. Montserrat-Martí G, Camarero JJ, Palacio S, Pérez-Rontomé C, Milla R, Albuixech J, Maestro M (2009) Summer-drought constraints the phenology and growth of two coexisting Mediterranean oaks with contrasting leaf habit: implications for their persistence and reproduction. Trees 23:787–799CrossRefGoogle Scholar
  35. Mudelsee M (2003) Estimating Pearson’s correlation coefficient with bootstrap confidence interval from serial dependent time series. Math Geol 35:651–665CrossRefGoogle Scholar
  36. Nabais C, Freitas H, Hagemeyer J (1998–1999) Tree-rings to climate relationships of Quercus ilex L. in the NE-Portugal. Dendrochronologia 16–17: 37–44Google Scholar
  37. Ogaya R, Peñuelas J (2007) Tree growth, mortality, and above-ground biomass accumulation in a holm oak forest under a five-year experimental field drought. Plant Ecol 189:291–299CrossRefGoogle Scholar
  38. Ogaya R, Peñuelas J, Martinez-Vilalta J, Mangiron M (2003) Effect of drought on diameter increment of Quercus ilex, Phillyrea latifolia, and Arbutus unedo in a holm oak forest of NE Spain. For Ecol Manag 180:175–184CrossRefGoogle Scholar
  39. Palamarev E (1989) Paleobotanical evidences of the Tertiary history and origin of the Mediterranean sclerophyll dendroflora. Plant Syst Evol 162:93–107CrossRefGoogle Scholar
  40. Terradas J, Savé R (1992) The influence of summer and winter stress and water relationships on the distribution of Quercus ilex L. Vegetatio 99–100:137–145CrossRefGoogle Scholar
  41. Venugopal N, Krishnamurthy KV (1987) Seasonal production of secondary xylem in the twigs of certain tropical trees. IAWA Bull 8:31–40Google Scholar
  42. Willmott CJ, Rowe CM, Mintz Y (1985) Climatology of the terrestrial seasonal water cycle. J Climatol 5:589–606CrossRefGoogle Scholar
  43. Zhang SH, Romane F (1991) Diameter growth of Quercus ilex L. and the interannual variability of climatic characteristics. Ann Sci For 48:225–234CrossRefGoogle Scholar
  44. Zweifel R, Item H, Hasler R (2001) Link between diurnal stem radius changes and tree water relations. Tree Physiol 21:869–877PubMedGoogle Scholar
  45. Zweifel R, Zeugin F, Zimmermann L, Newbery DM (2006) Intra-annual radial growth and water relations of trees -implications towards a growth mechanism. J Exp Bot 57:1445–1459PubMedCrossRefGoogle Scholar
