Cell and Tissue Research

, Volume 347, Issue 2, pp 397–406 | Cite as

Proliferative response of the stem cell system during regeneration of the rostrum in Macrostomum lignano (Platyhelminthes)

  • Freija Verdoodt
  • Wim Bert
  • Marjolein Couvreur
  • Katrien De Mulder
  • Maxime Willems
Regular Article
First Online:
Received:
Accepted:

Abstract

Macrostomum lignano (Platyhelminthes) possesses pluripotent stem cells, also called neoblasts, which power its extraordinary regeneration capacity. We have examined the cellular dynamics of neoblasts during regeneration of the rostrum in M. lignano. First, using live squeeze observations, the growth curve of the rostrum was determined. Second, neoblasts were labelled with 5-bromo-2'-deoxyuridine (BrdU) and an anti-phospho-histone H3 mitosis marker (anti-phos-H3) to analyze their proliferative response to amputation. During the regeneration process, both S- and M-phase cells were present anterior to the eyes, a region that is devoid of proliferating cells during homeostasis. Furthermore, BrdU pulse experiments revealed a biphasic S-phase pattern, different from the pattern known to occur during regeneration of the tail plate in M. lignano. During a first systemic phase, S-phase numbers significantly increased, both in the region adjacent to the wound (the anterior segment) and the region far from the wound (the posterior segment). During the second, spatially restricted phase, S-phase numbers in the anterior segment rose to a peak at 3 to 5 days post-amputation (p-a), while in the posterior segment, S-phase activity approached control values again. A blastema, characterized as a build-up of S- and M-phase cells, was formed 1 day p-a.

Altogether, our data present new insights into the cellular response of the neoblast system upon amputation, clearly demonstrating important differences from the situation known to occur during regeneration of the tail plate. Furthermore, the presence of proliferating cells in the region anterior to the eyes shows a clear alteration in stem cell regulation during regeneration.

Keywords

Macrostomum lignano Neoblasts Platyhelminthes S-phase Regeneration
This is a preview of subscription content, log in to check access.

Notes

Acknowledgements

We want to thank Bernhard Egger for advice concerning the BrdU labellings and for useful comments and discussions. Carl Vangestel is acknowledged for advice on statistical methods. Furthermore, the authors thank the anonymous reviewers for their insightful comments and suggestions, which have led to a significant improvement of the manuscript. FV and MW received funding from the Institute for the Promotion of Innovation through Science and Technology in Flanders (IWT-Vlaanderen).

Supplementary material

Supplementary Fig. 1

Scanning electron microscopy of the wound after amputation of the rostrum in M. lignano. a,b Scanning electron microscopic images of the rostrum region in M. lignano. a Control animal. Lateral view on the rostrum area. Ciliae of epidermal cells (arrowheads) and longer ciliae of sensory nerves (open arrowheads) are visible. Anterior is on top, ventral side is on the left. b One hour p-a. View on the anterior tip of the regenerating rostrum. The wound area is almost completely covered with a layer of epidermal cells, leaving only a small opening (asterisk). Ventral is on the left/bottom. Bars 10 μm

441_2011_1299_MOESM1_ESM.tif (7.7 mb)
High resolution (TIFF 7918 kb)
Supplementary Fig. 2

Immunostaining of muscle F-actin (phalloidin) after amputation of the rostrum in M. lignano. Confocal projections of the rostrum area after immunostaining of muscle F-actin, using TRITC-conjugated phalloidin. a Control animal, dorsal view. b One hour p-a, ventral view. Contraction of muscle fibers is visible at the level of the wound, resulting in a reduction of the wound area. Arrows indicate the level of the eyes. Anterior is on top. Bars 10 μm

441_2011_1299_MOESM2_ESM.tif (3 mb)
High resolution (TIFF 3100 kb)
Supplementary Fig. 3

Spatial distribution of S-phase cells during regeneration of the rostrum in M. lignano (BrdU pulse). BrdU labelling after a 30-minute BrdU pulse. a-i Confocal projections of the rostrum area. a Two hours p-a. b Eight hours p-a. c Three days p-a. d Four days p-a. e Five days p-a. f Seven days p-a. g Eight days p-a. h Nine days p-a. i Ten days p-a. Arrows indicate the level of the eyes. Anterior is on top. Bars 50 μm

441_2011_1299_MOESM3_ESM.tif (3.7 mb)
High resolution (TIFF 3756 kb)
Supplementary Fig. 4

Immunostaining of the serotonergic nervous system (anti 5-HT) after amputation of the rostrum in M. lignano. Confocal projections of the rostrum after immunostaining of neurons expressing the neuropeptide serotonin. a Control animal. Two condensed clusters of serotonergic neurons are present at the lateral sides of the neuropile (asterisks). Emanating from the neuropile are axons, which form a subepidermal plexus (see also Morris et al. 2007). b Zero hours p-a. The condensed clusters at the lateral sides of the neuropile are not damaged when amputation is performed at the indicated cutting level. c Two hours p-a. Neurons of the subepidermal plexus are present in the anterior tip of the rostrum. Arrows indicate the level of the eyes. Anterior is on top. Bars 10 μm

441_2011_1299_MOESM4_ESM.tif (4 mb)
High resolution (TIFF 4141 kb)

References

  1. Abramoff MD, Magelhaes PJ, Ram SJ (2004) Image processing with image. J Biophotonics Int 11:36–42Google Scholar
  2. Agata K (2003) Regeneration and gene regulation in planarians. Curr Opin Genet Dev 13:492–496PubMedCrossRefGoogle Scholar
  3. Baguñà J (1976) Mitosis in intact and regenerating planarian Dugesia mediterranea n.sp. 2. Mitotic studies during regeneration, and a possible mechanism of blastema formation. J Exp Zool 195:65–79CrossRefGoogle Scholar
  4. Baguñà J, Saló E, Romero R, Garciafernandez J, Bueno D, Munozmarmol AM, Bayascasramirez JR, Casali A (1994) Regeneration and pattern-formation in planarians - cells, molecules and genes. Zoolog Sci 11:781–795Google Scholar
  5. Bode A, Salvenmoser W, Nimeth K, Mahlknecht M, Adamski Z, Rieger RM, Peter R, Ladurner P (2006) Immunogold-labeled S-phase neoblasts, total neoblast number, their distribution, and evidence for arrested neoblasts in Macrostomum lignano (Platyhelminthes, Rhabditophora). Cell Tissue Res 325:577–587PubMedCrossRefGoogle Scholar
  6. Brøndsted HV (1969) Planarian Regeneration. Pergamon Press, OxfordGoogle Scholar
  7. De Mulder K, Kuales G, Pfister D, Egger B, Seppi T, Eichberger P, Borgonie G, Ladurner P (2010) Potential of Macrostomum lignano to recover from gamma-ray irradiation. Cell Tissue Res 339:527–542PubMedCrossRefGoogle Scholar
  8. Egger B, Ladurner P, Nimeth K, Gschwentner R, Rieger R (2006) The regeneration capacity of the flatworm Macrostomum lignano - on repeated regeneration, rejuvenation, and the minimal size needed for regeneration. Dev Genes Evol 216:565–577PubMedCrossRefGoogle Scholar
  9. Egger B, Gschwentner R, Hess MW, Nimeth KT, Adamski Z, Willems M, Rieger R, Salvenmoser W (2009) The caudal regeneration blastema is an accumulation of rapidly proliferating stem cells in the flatworm Macrostomum lignano. BMC Dev Biol 9:41PubMedCrossRefGoogle Scholar
  10. Guillard R, Ryther J (1962) Studies of marine planktonic diatoms. I. Cyclotella nana Hustedt, and Detonula confervacea (Cleve) Gran. Can J Microbiol 8:229–239PubMedCrossRefGoogle Scholar
  11. Ladurner P, Rieger R, Baguñà J (2000) Spatial distribution and differentiation potential of stem cells in hatchlings and adults in the marine platyhelminth Macrostomum sp.: A bromodeoxyuridine analysis. Dev Biol 226:231–241PubMedCrossRefGoogle Scholar
  12. Ladurner P, Schärer L, Salvenmoser W, Rieger RM (2005) A new model organism among the lower Bilateria and the use of digital microscopy in taxonomy of meiobenthic Platyhelminthes: Macrostomum lignano, n. sp. (Rhabditophora, Macrostomorpha). J Zool Syst Evol Res 43:114–126CrossRefGoogle Scholar
  13. Morris J, Cardona A, De Miguel-Bonet MDM, Hartenstein V (2007) Neurobiology of the basal platyhelminth Macrostomum lignano: map and digital 3D model of the juvenile brain neuropile. Dev Genes Evol 217:569–584PubMedCrossRefGoogle Scholar
  14. Mouton S, Willems M, Braeckman BP, Egger B, Ladurner P, Schärer L, Borgonie G (2009) The free-living flatworm Macrostomum lignano: A new model organism for ageing research. Exp Gerontol 44:243–249PubMedCrossRefGoogle Scholar
  15. Newmark PA, Sánchez Alvarado A (2000) Bromodeoxyuridine specifically labels the regenerative stem cells of planarians. Dev Biol 220:142–153PubMedCrossRefGoogle Scholar
  16. Nimeth KT, Mahlknecht M, Mezzanato A, Peter R, Rieger R, Ladurner P (2004) Stem cell dynamics during growth, feeding, and starvation in the basal flatworm Macrostomum sp. (Platyhelminthes). Dev Dyn 230:91–99PubMedCrossRefGoogle Scholar
  17. Nimeth KT, Egger B, Rieger R, Salvenmoser W, Peter R, Gschwentner R (2007) Regeneration in Macrostomum lignano (Platyhelminthes): cellular dynamics in the neoblast stem cell system. Cell Tissue Res 327:637–646PubMedCrossRefGoogle Scholar
  18. Palmberg I (1986) Cell-migration and differentiation during wound-healing and regeneration in Microstomum lineare (Turbellaria). Hydrobiologia 132:181–188CrossRefGoogle Scholar
  19. Paulus T, Muller MCM (2006) Cell proliferation dynamics and morphological differentiation during regeneration in Dorvillea bermudensis (Polychaeta, Dorvilleidae). J Morphol 267:393–403PubMedCrossRefGoogle Scholar
  20. Reddien PW, Sánchez Alvarado A (2004) Fundamentals of planarian regeneration. Annu Rev Cell Dev Biol 20:725–757PubMedCrossRefGoogle Scholar
  21. Reuter M, Kreshchenko N (2004) Flatworm asexual multiplication implicates stem cells and regeneration. Can J Zool 82:334–356CrossRefGoogle Scholar
  22. Saló E (2006) The power of regeneration and the stem-cell kingdom: freshwater planarians (Platyhelminthes). Bioessays 28:546–559PubMedCrossRefGoogle Scholar
  23. Saló E, Baguñà J (1984) Regeneration and pattern-formation in planarians.1. the pattern of mitosis in anterior and posterior regeneration in Dugesia (G) tigrina, and a new proposal for blastema formation. J Embryol Exp Morphol 83:63–80PubMedGoogle Scholar
  24. Saló E, Baguñà J (1985) Cell-movement in intact and regenerating planarians - quantitation using chromosomal, nuclear and cytoplasmic markers. J Embryol Exp Morphol 89:57–70PubMedGoogle Scholar
  25. Saló E, Baguñà J (2002) Regeneration in Planarians and other worms: New findings, new tools, and new perspectives. J Exp Zool 292:528–539PubMedCrossRefGoogle Scholar
  26. Salvenmoser W, Riedl D, Ladurner P, Rieger R (2001) Early steps in the regeneration of the musculature in Macrostomum sp. (Macrostomorpha). Belg J Zool 131:105–109Google Scholar
  27. Sánchez Alvarado A, Newmark PA (1998) The use of planarians to dissect the molecular basis of metazoan regeneration. Wound Repair Regen 6:413–420PubMedGoogle Scholar
  28. Schärer L, Ladurner P (2003) Phenotypically plastic adjustment of sex allocation in a simultaneous hermaphrodite. Proc R Soc Lond B Biol Sci 270:935–941CrossRefGoogle Scholar
  29. Wenemoser D, Reddien PW (2010) Planarian regeneration involves distinct stem cell responses to wounds and tissue absence. Dev Biol 344:979–991PubMedCrossRefGoogle Scholar
  30. Wilson A, Laurenti E, Oser G, van der Wath RC, Blanco-Bose W, Jaworski M, Offner S, Dunant CF, Eshkind L, Bockamp E, Lio P, MacDonald HR, Trumpp A (2008) Hematopoietic stem cells reversibly switch from dormancy to self-renewal during homeostasis and repair. Cell 135:1118–1129PubMedCrossRefGoogle Scholar
