Child's Nervous System

, Volume 32, Issue 1, pp 169–173 | Cite as

Intradural prepontine chordoma in an 11-year-old boy. A case report

  • R. Saman Vinke
  • Elise Charlotte Lamers
  • Benno Kusters
  • Erik J. van Lindert
Open Access
Case Report

Abstract

Case report

The authors report a case of an 11-year-old boy that presented with headache and vomiting that was present for several months. CT and MR imaging revealed a large prepontine mass and an obstructive hydrocephalus. A ventriculoperitoneal shunt was inserted, and in a second operation, a radiologically proven total resection was performed, using a left frontotemporal transsylvian approach. The tumour showed no involvement of the dura or clivus. Histological examination showed the characteristics of a chordoma. No further adjuvant treatment was given. The patient remained disease or tumour free after a 6-year follow-up.

Discussion

Intradural chordomas are extremely rare tumours that originate from notochordal remnants. Only three other cases have been reported in the paediatric population. Ecchordosis physaliphora (EP) is an ectopic notochordal remnant that has a similar biological behaviour and is difficult to distinguish from intradural chordomas. They might exist in a continuum from benign notochordal tumour to malignant chordoma. A surgical resection without adjuvant radiation therapy is suggested to be the treatment of choice in the paediatric population.

Conclusion

The authors describe a rare case of an intradural prepontine chordoma in an 11-year-old boy that stayed disease free after a 6-year follow-up.

Keywords

Chordoma Intradural Prepontine Paediatric

Introduction

Chordomas are rare, slow-growing tumours accounting for 1–4 % of all primary malignant bone tumours [11]. They usually occur in adults with a peak incidence between 50 and 60 years of age [16]. The incidence in children and adolescents is less than 5 % of the total incidence [4]. Chordomas are thought to arise from notochordal remnants throughout the axial skeleton and are most commonly located in the skull base, mobile spine and sacrum at an almost equal distribution [16]. Although intradural localization of chordomas is rare, several cases have been reported in the literature. However, most of the reported cases have occurred in adults and only three cases of a pure intradural chordoma in a paediatric patient have been reported [5, 9, 27]. In this report, we present a case of an intradural prepontine chordoma in an 11-year-old boy with a 6-year follow-up and an update of the literature.

Case report

An 11-year-old boy presented with a history of headaches and vomiting that had been present for several months. Physical examination showed papilledema without the presence of any other neurological deficits. Magnetic resonance imaging (MRI) revealed a large prepontine mass with dorsal displacement of the brainstem and a secondary obstructive hydrocephalus due to compression of the aqueduct. The lesion had an inhomogeneous hypointense aspect on the T1-weighted image (T1WI) and an inhomogeneous hyperintense aspect on the T2-weighted image (T2WI). After administration of IV gadolinium, there was some inhomogeneous enhancement (Fig. 1). Computed tomography (CT) imaging showed no bone involvement.
Fig. 1

Preoperative MR images. a, b Axial and parasagittal T2-weighted MRI scans showing an inhomogeneous hyperintense prepontine lesion with a mass effect on the brainstem. c, d Axial and parasagittal T1-weighted MRI scan after administration of gadolinium contrast show inhomogeneous enhancement. e Axial T1-weighted MRI scan shows an inhomogeneous hypointense prepontine lesion. f Parasagittal constructive interference steady state (CISS) MRI scan shows an inhomogeneous hyperintense prepontine lesion

Operation

During the first operation, a ventriculoperitoneal shunt was inserted into the right lateral ventricle to treat the hydrocephalus. A careful study of the MRI suggested that this infra- and supratentorially located tumour might be resected through a single approach. A left frontotemporal transsylvian approach was performed to gain access to the tumour. The tumour had well-defined margins and was entirely located in the intradural plane. There were no attachments to the cranial nerves or brainstem. A macroscopic complete resection was performed.

Postoperative course

Postoperatively, the patient had developed a left oculomotor nerve palsy, which completely recovered within the next 4 weeks. The postoperative MRI showed a complete removal of the tumour (Fig. 2). After careful consideration by a multidisciplinary team, we decided that there was no indication for postoperative radiation therapy. At follow-up one and a half years later, the patient was found to have remained asymptomatic. There were no signs of tumour recurrence on the MRI scan. At a follow-up of more than 6 years after treatment, there were still no signs of tumour recurrence on the MRI scan.
Fig. 2

Postoperative MR images. A complete tumour removal is shown on the a parasagittal T1-weighted sequence, b axial T2-weighted sequence and c axial T1-weighted sequence after administration of gadolinium contrast

Histopathological and immunohistochemical findings

Histological examination showed a slightly lobulated tumour consisting of a chondromyxoid matrix. The tumour cells showed a vacuolated and pale cytoplasm. Moderate nuclear polymorphism was observed but no obvious mitotic activity (Fig. 3). Some calcifications were seen. The tumour cells stained positive for pan-keratin, S-100 and epithelial membrane antigen (EMA). These findings suggest a histopathological diagnosis of chordoma.
Fig. 3

Histopathological imaging. The lesion shows vacuolated tumour cells with a pale cytoplasm and moderate nuclear polymorphism in a chondromyxoid matrix. These findings are a characteristic of chordoma

Discussion

Chordomas are rare primary bone tumours. Despite their low-grade histological characteristics, chordomas often show a malignant disease course [2, 21, 23]. Symptoms usually develop gradually, related to the relatively slow-growing tumour compressing the surrounding structures. However, chordomas can present with acute and progressive clinical symptoms due to intratumoral haemorrhage as well [22]. The extent of initial surgical resection has been shown to be the most important predictor of local tumour recurrence and long-term survival [6, 10, 14, 23].

Chordomas are most commonly located in the extradural space, with possible transdural progression. Purely intradurally localised chordomas are extremely rare with an incidence of 3.8 % of all chordoma cases. Nevertheless, several cases and even small case series have been reported in the literature [3, 20, 24]. To our knowledge, only three other cases of intradural chordoma have been reported in the paediatric population (Table 1).
Table 1

Reported cases of intradural chordomas in the paediatric population

Reference

Age (years)

Sex

Location

Resection

RTx

Follow-up

Recurrence

Dow et al. (2003) [9]

9

F

Right cerebellar hemisphere

Complete

No

14 months

No

Chang et al. (2008) [5]

9

M

Right prepontine cistern

Complete

No

12 months

No

Zhang et al. (2010) [27]

8

ND

ND

ND

ND

ND

ND

This case

11

M

Prepontine

Complete

No

6 years

No

RTx radiotherapy, ND no data available

Intradural chordomas tend to show different biological behaviour compared to classic chordomas. In contrast to classic chordomas, purely intradural chordomas seem to have well-defined tumour margins, do not show bone invasion and are less adhesive to the surrounding structures all of which improves the resectability [20]. This is likely to be a reason for the lower recurrence rate compared to typical chordomas. In the literature, several cases of intradural chordomas are reported in children and adults (for review, see Dow et al. [9] and Masui et al. [15]). None of the reported cases showed tumour recurrence after surgery, even in cases of subtotal resection. In contrast, typical chordomas often show recurrence, metastatic features and progression to death despite adequate surgical resection, which is sometimes followed by adjuvant radiation therapy or chemotherapy [12]. However, AlOtaibi et al. [1] suggest in a recent systematic review that in the adult population, intradural chordomas show a comparable biological behaviour to typical cranial base chordomas.

Chordomas are thought to originate from remnants of the embryological notochord throughout the axial skeleton. Whereas typical chordomas are localised extradurally with possible transdural progression, this pathophysiologic mechanism does not explain a purely intradural localisation of chordomas.

Ecchordosis physaliphora (EP) are ectopic notochordal remnants that are usually asymptomatic. An incidence of 1.5–2 % in autopsy studies and approximately 1.7 % in MRI studies has been found [8, 17, 19]. EPs are typically found in the prepontine cistern, attached to the dorsal clivus with a small pedicle [13, 25]. Other distinctive features are that EPs generally occur in younger people compared to intradural chordomas and that EPs show no enhancement after gadolinium administration on MR imaging, whereas intradural chordomas show a variable enhancement [7, 17]. Although differentiating between symptomatic EPs and intradural chordomas based on histology is difficult and debated, Yamaguchi et al. [26] suggested some histological differentiating features. Symptomatic EPs and intradural chordomas tend to show a similar benign behaviour with a very low risk of tumour recurrence after surgical resection [7]. Chang et al. [5] suggest that EPs and intradural chordomas exist in a continuum from benign hamartomas to aggressive typical chordomas.

Treatment of a classic chordoma involves extensive surgery, sometimes combined with adjuvant radiation therapy [23]. There is not enough data available to postulate an evidence-based treatment for intradural chordomas in the paediatric population. One should consider that all of the reported cases (Table 1) were treated with a complete surgical resection without any adjuvant treatment, and none of these tumours did reoccur. Even cases in adults treated with a subtotal resection without adjuvant therapy did not show tumour recurrence after a 5-year follow-up [18]. Therefore, the role of adjuvant radiation therapy for intradural chordomas is debated. Considering the potential deleterious effect on the paediatric brain, radiation therapy should be avoided in the paediatric population. The authors postulate that a complete surgical resection without adjuvant radiation therapy should be the treatment of choice.

Conclusion

Although extremely rare, an intradural chordoma should be considered in the differential diagnosis of intradural prepontine lesions. The authors postulate that a complete surgical resection without adjuvant radiation therapy is the treatment of choice and that adjuvant radiation therapy should be avoided in the paediatric population. Additional studies are required to improve our knowledge about intradural chordomas and their treatment.

Notes

Disclosure

The authors report no conflicts of interest.

References

  1. 1.
    AlOtaibi F, Guiot MC, Muanza T, Di Maio S (2014) Giant petroclival primary intradural chordoma: case report and systematic review of the literature. J Neurol Surg Rep 75:e160–e169. doi: 10.1055/s-0034-1378157 CrossRefPubMedCentralPubMedGoogle Scholar
  2. 2.
    Bergh P, Kindblom LG, Gunterberg B, Remotti F, Ryd W, Meis-Kindblom JM (2000) Prognostic factors in chordoma of the sacrum and mobile spine: a study of 39 patients. Cancer 88:2122–2134CrossRefPubMedGoogle Scholar
  3. 3.
    Bergmann M, Abdalla Y, Neubauer U, Schildhaus HU, Probst-Cousin S (2010) Primary intradural chordoma: report on three cases and review of the literature. Clin Neuropathol 29:169–176CrossRefPubMedGoogle Scholar
  4. 4.
    Borba LA, Al-Mefty O, Mrak RE, Suen J (1996) Cranial chordomas in children and adolescents. J Neurosurg 84:584–591. doi: 10.3171/jns.1996.84.4.0584 CrossRefPubMedGoogle Scholar
  5. 5.
    Chang SW, Gore PA, Nakaji P, Rekate HL (2008) Juvenile intradural chordoma: case report. Neurosurgery 62:E525–E526 discussion E527. doi: 10.1227/01.neu.0000316022.74162.00 CrossRefPubMedGoogle Scholar
  6. 6.
    Cheng EY, Ozerdemoglu RA, Transfeldt EE, Thompson Jr RC (1999) Lumbosacral chordoma. Prognostic factors and treatment. Spine (Phila Pa 1976) 24:1639–1645CrossRefGoogle Scholar
  7. 7.
    Ciarpaglini R, Pasquini E, Mazzatenta D, Ambrosini-Spaltro A, Sciarretta V, Frank G (2009) Intradural clival chordoma and ecchordosis physaliphora: a challenging differential diagnosis: case report. Neurosurgery 64:E387–E388 discussion E388. doi: 10.1227/01.NEU.0000337064.57270.F0 CrossRefPubMedGoogle Scholar
  8. 8.
    Congdon CC (1952) Benign and malignant chordomas; a clinico-anatomical study of twenty-two cases. Am J Pathol 28:793–821PubMedCentralPubMedGoogle Scholar
  9. 9.
    Dow GR, Robson DK, Jaspan T, Punt JA (2003) Intradural cerebellar chordoma in a child: a case report and review of the literature. Childs Nerv Syst 19:188–191. doi: 10.1007/s00381-002-0707-8 PubMedGoogle Scholar
  10. 10.
    Forsyth PA, Cascino TL, Shaw EG, Scheithauer BW, O'Fallon JR, Dozier JC, Piepgras DG (1993) Intracranial chordomas: a clinicopathological and prognostic study of 51 cases. J Neurosurg 78:741–747. doi: 10.3171/jns.1993.78.5.0741 CrossRefPubMedGoogle Scholar
  11. 11.
    Healey JH, Lane JM (1989) Chordoma: a critical review of diagnosis and treatment. Orthop Clin N Am 20:417–426Google Scholar
  12. 12.
    Kaneko Y, Sato Y, Iwaki T, Shin RW, Tateishi J, Fukui M (1991) Chordoma in early childhood: a clinicopathological study. Neurosurgery 29:442–446CrossRefPubMedGoogle Scholar
  13. 13.
    Katayama Y, Tsubokawa T, Hirasawa T, Takahata T, Nemoto N (1991) Intradural extraosseous chordoma in the foramen magnum region. Case report. J Neurosurg 75:976–979. doi: 10.3171/jns.1991.75.6.0976 CrossRefPubMedGoogle Scholar
  14. 14.
    Kayani B, Sewell MD, Hanna SA, Saifuddin A, Aston W, Pollock R, Skinner J, Molloy S, Briggs TW (2014) Prognostic factors in the operative management of dedifferentiated sacral chordomas. Neurosurgery. doi: 10.1227/NEU.0000000000000423 PubMedGoogle Scholar
  15. 15.
    Masui K, Kawai S, Yonezawa T, Fujimoto K, Nishi N (2006) Intradural retroclival chordoma without bone involvement—case report. Neurol Med Chir 46:552–555CrossRefGoogle Scholar
  16. 16.
    McMaster ML, Goldstein AM, Bromley CM, Ishibe N, Parry DM (2001) Chordoma: incidence and survival patterns in the United States, 1973–1995. Cancer Causes Control 12:1–11CrossRefPubMedGoogle Scholar
  17. 17.
    Mehnert F, Beschorner R, Kuker W, Hahn U, Nagele T (2004) Retroclival ecchordosis physaliphora: MR imaging and review of the literature. AJNR Am J Neuroradiol 25:1851–1855PubMedGoogle Scholar
  18. 18.
    Nishigaya K, Kaneko M, Ohashi Y, Nukui H (1998) Intradural retroclival chordoma without bone involvement: no tumor regrowth 5 years after operation. Case report. J Neurosurg 88:764–768. doi: 10.3171/jns.1998.88.4.0764 CrossRefPubMedGoogle Scholar
  19. 19.
    Ribbert H (1904) Geschwulstlehre für Aerzte und Studierende. F. Cohen, BonnGoogle Scholar
  20. 20.
    Roberti F, Sekhar LN, Jones RV, Wright DC (2007) Intradural cranial chordoma: a rare presentation of an uncommon tumor. Surgical experience and review of the literature. J Neurosurg 106:270–274. doi: 10.3171/jns.2007.106.2.270 CrossRefPubMedGoogle Scholar
  21. 21.
    Schwab JH, Boland PJ, Agaram NP, Socci ND, Guo T, O'Toole GC, Wang X, Ostroumov E, Hunter CJ, Block JA, Doty S, Ferrone S, Healey JH, Antonescu CR (2009) Chordoma and chondrosarcoma gene profile: implications for immunotherapy. Cancer Immunol Immunother 58:339–349. doi: 10.1007/s00262-008-0557-7 CrossRefPubMedCentralPubMedGoogle Scholar
  22. 22.
    Uda T, Ohata K, Takami T, Hara M (2006) An intradural skull base chordoma presenting with acute intratumoral hemorrhage. Neurol India 54:306–307CrossRefPubMedGoogle Scholar
  23. 23.
    Walcott BP, Nahed BV, Mohyeldin A, Coumans JV, Kahle KT, Ferreira MJ (2012) Chordoma: current concepts, management, and future directions. Lancet Oncol 13:e69–e76. doi: 10.1016/S1470-2045(11)70337-0 CrossRefPubMedGoogle Scholar
  24. 24.
    Wang L, Wu Z, Tian K, Li G, Zhang J (2013) Clinical and pathological features of intradural retroclival chordoma. World Neurosurg. doi: 10.1016/j.wneu.2012.12.037 Google Scholar
  25. 25.
    Wolfe 3rd JT, Scheithauer BW (1987) “Intradural chordoma” or “giant ecchordosis physaliphora”? Report of two cases. Clin Neuropathol 6:98–103PubMedGoogle Scholar
  26. 26.
    Yamaguchi T, Suzuki S, Ishiiwa H, Shimizu K, Ueda Y (2004) Benign notochordal cell tumors: a comparative histological study of benign notochordal cell tumors, classic chordomas, and notochordal vestiges of fetal intervertebral discs. Am J Surg Pathol 28:756–761CrossRefPubMedGoogle Scholar
  27. 27.
    Zhang QH, Kong F, Guo HC, Chen G (2010) Nasal endoscopic resection of extended intradural clival chordoma. Zhonghua Er Bi Yan Hou Tou Jing Wai Ke Za Zhi 45:542–546PubMedGoogle Scholar
