Reconstruction of an Isolated Left Subclavian Artery in a Patient with a Right Aortic Arch and Tetralogy of Fallot

A 2-year-old boy was referred to our facility for surgical repair of a tetralogy of Fallot (TOF) that had no symptoms suggestive of vertebrobasilar insufficiency or ischemia of the upper extremity. Preoperative angiography showed an absence of the left subclavian artery (LSA) in the early phase and a delayed retrograde flow through the left vertebral artery into an isolated left subclavian artery (ILSA).

The ILSA was anastomosed to the left common carotid artery in an end-to-side fashion during repair of the associated TOF. Follow-up angiography demonstrated antegrade flow into the LSA and the left vertebral artery, respectively (Fig. 1).

Open image in new window

In planning the reconstruction of the ILSA, multidetector-row computed tomography (MDCT) angiography was used to provide the morphology of the major arteries, including the spatial relationship between the left common carotid artery and the ILSA (Fig. 2). In preoperative planning, surgeons can use MDCT to assess the length of dissection along the nonpalpable vessel necessary to access an ideal site for the anastomosis on the common carotid artery.

Open image in new window

It still is controversial whether an ILSA should be reconstructed. The literature contains little comprehensive study of this particular disease because of its rarity. Luetmer and Miller [1] reported that 5 (17%) of 30 patients with ILSA had symptoms of ischemia in the upper extremity and that another 5 had symptoms suggestive of vertebrobasilar insufficiency. Apparently many surgeons are likely to abandon an LSA reconstruction, preferring to perform a simple ligation to save time and avoid a more complex procedure in the belief that the frequency of steal syndrome will be reduced. However, ischemic symptoms of the upper extremity or vertebrobasilar insufficiency can emerge years after LSA ligation [1, 2].

We believe that with an ILSA, we should make the best effort to reconstruct. To the best of our knowledge, this is the first reported case in which an ILSA reconstruction was determined to be beneficial by angiography. An antegrade flow may be effective in preventing future symptoms of steal syndrome late after surgery.
