Bulletin of Volcanology

, Volume 53, Issue 7, pp 546–558 | Cite as

Structure, and origin by injection of lava under surface crust, of tumuli, “lava rises”, “lava-rise pits”, and “lava-inflation clefts” in Hawaii

  • George P L Walker
Article

Abstract

Tumuli are positive topographic features that are common on Hawaiian pahoehoe lava flow fields, particularly on shallow slopes, and 75 measured examples are presented here to document the size range. Tumuli form by up-tilting of crustal plates, without any crustal shortening, and are thus distinguished from pressure ridges which are up-buckled by laterally directed pressure. The axial or star-like systems of deep clefts that characterize tumuli are defined here as “lava-inflation clefts”; their tips advanced into red-hot lava and they widened as uplift proceeded and while the lava crust was thickening. Flat-surfaced uplifts, formed like tumuli by injection of lava under a surface crust, were previously called pressure plateaus, but “lava rise” is proposed instead. The pits that abound among lava rises, previously attributed to collapse or subsidence, are generally formed because the lava around them rose, and the name “lava-rise pit” is proposed. Unique examples of tumuli and lava rises, from which lava drained out under a surface crust 1.5 to 2.5 m thick, are described from Kilauea caldera. These examples show that in tumuli and lava rises the crust floats on considerable bodies of fluid lava, and is able to do so because of its higher vesicle content: the fluid lava loses many of its gas bubbles during residence beneath the crust. The bulk densities of samples from tumuli show a general downward increase. The form of the density profile is consistent with the relationship that for any given crustal thickness the density of fluid lava closely matched the average density of that crust, suggesting that the lava was stably density-stratified. It is inferred that stable stratification was regulated by out-flows of the more vesicular lava fractions, loss of bubbles through the lava-inflation clefts, and entry of injected lava at its level of neutral buoyancy. Below the uppermost meter the downward decrease in vesicularity closely conforms with that expected by compression of a uniform mass of gas per unit mass of lava.

Keywords

Lava Flow Fluid Lava Surface Crust Neutral Buoyancy Deep Cleft
These keywords were added by machine and not by the authors. This process is experimental and the keywords may be updated as the learning algorithm improves.

Preview

Unable to display preview. Download preview PDF.

Unable to display preview. Download preview PDF.

References

  1. Anderson SW, Fink JH (1988) Crease structures as lava emplacement rate indicators (abstr). EOS 69:1486Google Scholar
  2. Anderson T (1910) The volcano of Matavanu in Savaii. Geol Soc Lond Quart J 66:621–639Google Scholar
  3. Aubele JC, Crumpler LS, Elston W (1988) Vesicle zonation and vertical structure of basalt flows. J Volcanol Geotherm Res 35:349–374Google Scholar
  4. Bartrum JA (1928) Lava slickensides at Auckland. NZ J Sci Technol 10:23–25Google Scholar
  5. Bullard FM (1976) Volcanoes of the Earth. University of Texas Press, Austin, 579 ppGoogle Scholar
  6. Champion DE, Greeley R (1977) Geology of the Wapi lava field, Snake River Plain, Idaho. In: Greely R, King JS (eds) Volcanism of the eastern Snake River Plain, Idaho. NASA: 133–152Google Scholar
  7. Cotton CA (1952) Volcanoes as landscape forms. Hafner Pub Co, New York, 416 ppGoogle Scholar
  8. Daly RS (1914) Igneous rocks and their origin. McGraw Hill, New YorkGoogle Scholar
  9. Dana JD (1887) Characteristics of volcanoes. Dodd, Mead and Co, New York, 399 ppGoogle Scholar
  10. Francis PW, Roobol MJ, Walker GPL, Cobbold PR, Coward M (1974) The San Pedro and San Pablo volcanoes of northern Chile and their hot avalanche deposits. Geol Rdsch 63:357–388Google Scholar
  11. Friedländer I (1914) Über die Kleinformen der vulkanischen Produkte. III Laven. Zeit Vulkan 1:219–224Google Scholar
  12. Gary M, McAfee R, Wolf CL (eds) (1972) Glossary of Geology. Am Geol InstGoogle Scholar
  13. Green J, Short NM (1971) Volcanic landforms and surface features. Springer, Berlin Heidelberg New York, pp 519Google Scholar
  14. Guba I, Mustafa H (1988) Structural control of young basaltic fissure eruptions in the plateau basalt area of the Arabian plate, northeastern Jordan. J Volcan Geotherm Res 35:319–334Google Scholar
  15. Guest JE, Wood C, Greeley R (1984) Lava tubes, terraces and megatumuli on the 1614–24 pahoehoe lava flow field, Mount Etna, Sicily. Bull Volcan 49:635–648Google Scholar
  16. Hardee HC (1980) Solidification in Kilauea Iki lava lake. J Volcan Geotherm Res 7:211–223Google Scholar
  17. Jaggar TA (1931) Lava stalactites, stalagmites, toes and “squeeze-ups”. The Volcano Letter, Hawaiian Volcano Obs, no 345:1–2Google Scholar
  18. James AVG (1920) Factors producing columnar jointing in lavas. J Geol 28:458–469Google Scholar
  19. Macdonald GA (1967) Forms and structures of extrusive basaltic rocks. In: Hess HH, Poldervaart A (eds) Basalts. The Poldervaart treatise on rocks of basaltic composition. Interscience Publ, New York Vol 1: 1–61Google Scholar
  20. Macdonald GA (1972) Volcanoes Prentice-Hall, Englewood Cliffs, NJ. 510 ppGoogle Scholar
  21. Murase T, McBirney AR (1973) Properties of some common igneous rocks and their melts at high temperatures. Geol Soc Am Bull 84:3563–3592Google Scholar
  22. Nichols RL (1939) Surficial banding and shark's-tooth projections in the cracks of basaltic lava. Am J Sci 237:188–194Google Scholar
  23. Nichols RL (1946) McCartys basalt flow, Valencia Country, New Mexico. Geol Soc Am Bull 57:1049–1086Google Scholar
  24. Ollier C (1969) Volcanoes. Austral Natl Univ Press, Canberra, 177 ppGoogle Scholar
  25. Ollier C (1988) Volcanoes. Blackwell, Oxford, 228 ppGoogle Scholar
  26. Peck DL (1978) Cooling and vesiculation of Alae lava lake, Hawaii. US Geol Surv Prof Pap 935-B, 59 ppGoogle Scholar
  27. Peck DL, Wright TL, Moore JG (1966) Crystallization of tholeiitic basalt in Alae lava lake, Hawaii. Bull Volcan 29:629–655Google Scholar
  28. Perret FA (1950) Volcanological observations. Carnegie Instn, Washington Pub 549, 162 pGoogle Scholar
  29. Rowland SK, Walker GPL (1987) Toothpaste lava: characteristics and origin of a lava structural type transitional between pahoehoe and aa. Bull Volcan 49:577–587Google Scholar
  30. Russell IC (1902) Geology and water resources of the Snake River Plains of Idaho. US Geol Surv Bull 199: 192 ppGoogle Scholar
  31. Ryan MP, Sammis CG (1978) Cyclic fracture mechanisms in cooling basalt. Geol Soc Am Bull 89:1295–1308Google Scholar
  32. Sapper K (1919) Über hornitos und verwandt gebilde. Zeit Vulcan 5:1–39Google Scholar
  33. Skeats EW, James AVG (1937) Basaltic barriers of western Victoria. Proc R Soc Victoria 49 (n s): 245–278Google Scholar
  34. Swanson DA (1973) Pahoehoe flows from the 1969–1971 Mauna Ulu eruption, Kilauea volcano, Hawaii. Geol Soc Am Bull 84:615–626Google Scholar
  35. Swanson DA, Dzurisin D, Holcomb RT, Iwatsubo EY, Chadwick WW, Casadevall TJ, Ewart JW, Heliker CC (1987) Growth of the lava dome at Mount St Helens, Washington, (USA), 1981–1983. Geol Soc Am Spec Pap 212:1–16Google Scholar
  36. Tyrrell GW (1931) Volcanoes. Henry Holt and Co, New York, 252 ppGoogle Scholar
  37. Waesche HH (1940) Mauna Loa summit crater eruption, 1940. The Volcano Letter, no 468: 1–9Google Scholar
  38. Walker GPL (1969) The breaking of magma. Geol Mag 106:166–173Google Scholar
  39. Walker GPL (1989) Spongy pahoehoe in Hawaii: a study of vesicle-distribution patterns in basalt and their significance. Bull Volcanol 51:199–209Google Scholar
  40. Watanabe K, Katsui Y (1976) Pseudo-pillow lavas in the Aso caldera, Kyushu, Japan. J Jap Assoc Mineral Petrol Econ Geol 71:44–49Google Scholar
  41. Wentworth CK, Macdonald GA (1953) Structures and forms of basaltic rocks in Hawaii. US Geol Surv Bull 994, 98 ppGoogle Scholar
  42. Williams H, McBirney AR (1979) Volcanology. Freeman Cooper and Co, San Francisco, 397 ppGoogle Scholar
  43. Wright TL, Okamura RT (1977) Cooling and crystallization of tholeiitic basalt, 1965 Makaopuhi lava lake, Hawaii. US Geol Surv Prof Pap 1004. 78 pGoogle Scholar

Copyright information

© Springer-Verlag 1991

Authors and Affiliations

  • George P L Walker
    • 1
  1. 1.Hawaii Institute of GeophysicsHonoluluUSA
