Solar Physics

, Volume 24, Issue 1, pp 43–58 | Cite as

Space and time variations of the solar Na D line profiles

  • C. D. Slaughter
  • A. M. Wilson
Article
Revised:

Abstract

Preliminary results are presented of observations of the solar Na D lines obtained with high space and time resolution (2.4″ × 2.4″), (6 s). The following conclusions may be drawn.
  1. (i)

    The line profiles vary strongly with space and time implying that time averaging over a long period and large area will not produce the ‘true’ profile.


  2. (ii)

    The centre-limb increase in apparent Doppler width in the D lines is intrinsic. It is not due to space or time averaging.


  3. (iii)

    The amplitude of the 300-s oscillation may range up to 1.5 km/s in the region of formation of the D lines. Large line asymmetries are associated with this motion. Observations which do not resolve this motion can not be considered adequate.


  4. (iv)

    The variation of the D line profile caused by the 300-s oscillation may be described as follows: (a) The core is raised and lowered without change of shape, (b) The wings broaden as the central intensity rises and narrow as it falls. These variations are qualitatively explained by the scanning of the line formation region through the solar atmosphere.


  5. (v)

    Doppler width values derived from pairs of D line profiles are strongly correlated with the motion of the element observed. Hotter elements move upward, cooler downward.


  6. (vi)

    Indications of running waves have been found in the time variation of the core line bisectors.



The profile variations observed provide a framework in which various properties of the centre limb variation of these lines may be considered. In particular they show that any expectation of accuracy in profile coincidence above a certain value must be doomed by the intrinsic variability of the solar atmosphere.

Keywords

Time Variation Central Intensity Line Profile Solar Atmosphere Formation Region
These keywords were added by machine and not by the authors. This process is experimental and the keywords may be updated as the learning algorithm improves.
This is a preview of subscription content, log in to check access.

Preview

Unable to display preview. Download preview PDF.

Unable to display preview. Download preview PDF.

References

  1. Allen, C. W.: 1939, Monthly Notices Roy. Astron. Soc. 100, 10.Google Scholar
  2. Athay, R. G. and Canfield, W.: 1969, Astrophys. J. 156, 695.Google Scholar
  3. Brault, J. W.: 1962, Thesis Princeton University.Google Scholar
  4. Brault, J. W. and White, O. R.: 1971, Astron. Astrophys. (to be published).Google Scholar
  5. Brault, J. W., Slaughter, C. D., Pierce, A. K., and Aikens, R. S.: 1971, Solar Phys. 18, 366.Google Scholar
  6. Curtis, G. W. and Jefferies, J. T.: 1967, Astrophys. J. 150, 1061.Google Scholar
  7. Frazier, E. N.: 1967, Z. Astrophys. 68, 345.Google Scholar
  8. Frazier, E. N.: 1968, Astrophys. J. 152, 557.Google Scholar
  9. Gonczi, G. and Roddier, F.: 1969, Solar Phys. 8, 255.Google Scholar
  10. Gonczi, G. and Roddier, F.: 1971, Astron. Astrophys. 11, 28.Google Scholar
  11. Hines, C. O.: 1960, J. Phys. 38, 1441.Google Scholar
  12. Ivanov, V. V.: 1963, Sov. Astron. 6, 793.Google Scholar
  13. Jefferies, J. T.: 1968, Spectral Line Formation, Ginn-Blaisdell.Google Scholar
  14. Leibacher, J.: 1971, Thesis Harvard University.Google Scholar
  15. Olson, E. C.: 1966, Astrophys. J. 143, 904.Google Scholar
  16. Pierce, A. K.: 1964, Kitt Peak Contributions, No. 65.Google Scholar
  17. Pierce, A. K.: 1970, Private communication.Google Scholar
  18. Risberg, P.: 1956, Arkiv Fysik 10, 583.Google Scholar
  19. Sheeley, N. G.: 1970, Private communication.Google Scholar
  20. Snider, J. L.: 1970, Solar Phys. 12, 352.Google Scholar
  21. Uhlrich, R. K.: 1970, Astrophys. J. 162, 993.Google Scholar
  22. Waddell, J. H.: 1962, Astrophys. J. 136, 223.Google Scholar
  23. Waddell, J. H.: 1963, Astrophys. J. 137, 1210.Google Scholar
  24. White, O. R.: 1971, Private communication.Google Scholar
  25. Wilson, A. M. and Worrall, G.: 1969, Astron. Astrophys. 2, 458.Google Scholar
  26. Worrall, G.: 1971, Astron. Astrophys. 12, 88.Google Scholar

Copyright information

© D. Reidel Publishing Company 1972

Authors and Affiliations

  • C. D. Slaughter
    • 1
  • A. M. Wilson
    • 2
  1. 1.Solar DivisionKitt Peak National ObservatoryTucsonU.S.A.
  2. 2.Solar Atmosphere BranchLaboratory for Solar Physics, NASA-Goddard Space Flight CenterGreenbelt, Md.U.S.A.
