Abstract
The Chalk is an important water supply aquifer, yet ecosystems within it remain poorly understood. Boreholes (198) in seven areas of England (UK) were sampled to determine the importance of the Chalk aquifer as a habitat, and to improve understanding of how species are distributed. Stygobitic macro-invertebrates were remarkably common, and were recorded in 67 % of boreholes in unconcealed Chalk, although they were not recorded in Chalk that is concealed by low-permeability strata and thus likely to be confined. Most species were found in shallow boreholes (<21 m) and boreholes with deep (>50 m) water tables, indicating that the habitat is vertically extensive. Stygobites were present in more boreholes in southern England than northern England (77 % compared to 38 %). Only two species were found in northern England compared to six in southern England, but overall seven of the eight stygobitic macro-invertebrate species found in England were detected in the Chalk. Two species are common in southern England, but absent from northern England despite the presence of a continuous habitat prior to the Devensian glaciation. This suggests that either they did not survive glaciations in the north where glaciers were more extensive, or dispersal rates are slow and they have never colonised northern England. Subsurface ecosystems comprising aquatic macro-invertebrates and meiofauna, as well as the microbial organisms they interact with, are likely to be widespread in the Chalk aquifer. They represent an important contribution to biodiversity, and may influence biogeochemical cycles and provide other ecosystem services.
Résumé
La craie est un aquifère important pour l’alimentation en eau, pourtant les écosystèmes qu’elle abrite demeurent mal compris. Des forages (198) dans sept régions d’Angleterre (UK) ont été échantillonnés pour déterminer l’importance de l’aquifère de la Craie en tant qu’habitat, et pour améliorer la connaissance sur le mode de distribution des espèces. Les macro-invertébrés stygobies sont relativement communs: ils ont été rencontrés dans 67 % des forages dans la craie sans couverture, mais on ne les a pas trouvé dans la Craie recouverte par une couche de faible perméabilité et susceptible d’être captive. La plupart des espèces a été rencontrée à la fois dans des forages peu profonds (<21 m) et des forages où la nappe est profonde (>50 m), indiquant que l’habitat s’étend verticalement. Les stygobies étaient d’avantage présents dans les régions du Sud de l’Angleterre que dans celles du Nord (77 % respectivement 38 %). Seulement deux espèces ont été trouvées dans le Nord de l’Angleterre par rapport à six dans le Sud, mais au total, sept espèces de macro-invertébrés stygobies sur huit trouvées en Angleterre l’ont été dans la Craie. Deux espèces sont communes dans le Sud de l’Angleterre, mais absentes du Nord, malgré la présence d’un habitat continu, antérieur à la glaciation Devensienne. Cela suggère soit qu’elles n’ont pas survécu aux glaciations dans le Nord, où les glaciers étaient plus étendus, soit que les vitesses de dispersion sont lentes et qu’elles n’ont jamais colonisé le Nord de l’Angleterre. Les écosystèmes de sub-surface, comprenant les macro-invertébrés aquatiques et la méiofaune, ainsi que les organismes microbiens avec lesquels ils interagissent, sont susceptibles d’être répandus dans l’aquifère de la Craie. Ils représentent une importante contribution à la biodiversité et peuvent influencer les cycles biogéochimiques et procurer d’autres services écosystémiques
Resumen
El Chalk es un importante acuífero de abastecimiento de agua, sin embargo, los ecosistemas dentro de él siguen siendo poco conocidos. Se tomaron muestras en pozos (198) en siete áreas de Inglaterra (Reino Unido) para determinar la importancia del acuífero Chalk como un hábitat, y para mejorar la comprensión de cómo se distribuyen las especies. Los macroinvertebrados Stygobitic fueron notablemente comunes, y se registraron en el 67 % de los pozos no ocultos del Chalk, aunque no se registraron en el Chalk que se oculta por los estratos de baja permeabilidad y por lo tanto con alta probabilidad de ser confinado. La mayoría de las especies se encontraron en perforaciones con niveles freáticos someros (<21 m) y profundos (>50 m), lo que indica que el hábitat es verticalmente extenso. Los Stygobites estaban presentes en más pozos en el sur que en el norte de Inglaterra (77 % frente a 38 %). Sólo se encontraron dos especies en el norte de Inglaterra en comparación con seis en el sur, pero en general siete de las ocho especies de macro-invertebrados stygobitic encontradas en Inglaterra se detectaron en la Chalk. Dos especies son comunes en el sur de Inglaterra, pero están ausentes en el norte de Inglaterra a pesar de la presencia de un hábitat continuo antes de la glaciación Devensiana. Esto sugiere que, o bien ellos no sobrevivieron glaciaciones en el norte, donde los glaciares eran más extensos, o los ritmos de dispersión son lentos y nunca han colonizado el norte de Inglaterra. Los ecosistemas del subsuelo comprenden macro-invertebrados acuáticos y meiofauna, así como los organismos microbianos que interactúan, es probable que sean muy extendidas en el acuífero de Chalk. Ellos representan una contribución importante a la biodiversidad, y pueden influir en los ciclos biogeoquímicos y proporcionar otros servicios a los ecosistemas.
摘要
白垩层是重要的供水含水层,但是其内部的生态系统仍然鲜为人知。对英国7个地区的(198个)钻孔进行了采样,以确定白垩层含水层作为气息地的重要性并且增进了解了物种是怎么样分布的。Stygobitic(洞穴生物)巨型无脊椎动物非常常见,在未埋藏的白垩层钻孔中,67%发现有此类物种, 尽管在低渗透性地层封闭的、很可能是承压的白垩层中没有发现此类物种。大多数物种出现于浅层钻孔(21 m)及水位深(>50 m)的钻孔中,表明栖息地是垂向广泛分布的。英格兰南部与英格兰北部相比,南部有更多的钻孔发现有Stygobites(77%比38%)。只有两个物种发现于英格兰北部,而南部发现有六个物种,但英格兰发现的八个 Stygobitic大型无脊椎动物物种只有七中在白垩层中检测到。两个物种在英格兰南部非常普遍,但在北部缺失,尽管在末期冰期之前存在着连续的栖息地。这表明他们不是在冰川分布较广的北部幸免于冰川作用,就是分散率太低,从来没有居住在英格兰北部。包括水生大型无脊椎动物和小型底栖生物以及与其进行反应的微生物的地表以下态系统很可能在白垩含水层中广泛分布。他们对生物多样性作出了重要贡献,可能影响着生物地球化学循环,并且提供着其他生态系统服务项目 。
Resumo
O Cré é um aquífero importante para o abastecimento de água, no entanto os ecossistemas que suporta são ainda pouco conhecidos. Foram recolhidas amostras em furos (198) de sete áreas na Inglaterra (Reino Unido) de forma a determinar a importância do aquífero do Cré como habitat e melhorar a compreensão sobre a distribuição das espécies. Macroinvertebrados de água subterrânea foram surpreendentemente comuns, tendo sido registados em 67 % dos furos de zonas em que o Cré é aflorante, no entanto não houveram registos em furos onde o Cré se encontra sobreposto por camadas pouco permeáveis e onde provavelmente é confinado. A maioria das espécies foram encontradas em furos pouco profundos (<21 m) e em furos com níveis freáticos profundos (>50 m), indicando que o habitat é verticalmente extenso. Estigobiontes foram mais presentes em furos no sul do que no norte da Inglaterra (77 % em comparação com 38 %). Apenas duas espécies foram detectadas no norte de Inglaterra, em comparação com seis encontradas no sul, no entanto no total das oito espécies de estigobiontes macro-invertebrados de água subterrânea conhecidas na Inglaterra, sete foram detectadas no Cré. Duas espécies são comuns no sul da Inglaterra, mas ausentes no norte, apesar da presença de um habitat contínuo no período anterior à glaciação Devensiana. Isto sugere que ou não sobreviveram às glaciações no norte, onde os glaciares foram mais extensos, ou que a sua dispersão é lenta e que ainda não colonizaram o norte da Inglaterra. Ecossistemas subterrâneos compostos por macro-invertebrados aquáticos e meiofauna, tal como organismos microbiais com os quais interagem, são provavelmente prevalecentes no aquífero do Cré. Estes representam uma importante contribuição para a biodiversidade e poderão influenciar ciclos biogeoquímicos e fornecer outros serviços ecossistêmicos.
Similar content being viewed by others
Introduction
This report describes the first national-scale study of groundwater ecology in a single geological unit, the Chalk aquifer (England, UK). Groundwater contains ecosystems comprising micro-organisms, meiofauna (organisms usually less than 1 mm in length), and larger macro-invertebrates (animals easily visible to the naked eye). In this study, boreholes were sampled for macro-invertebrates, which are the largest organisms present in non-cavernous groundwater, and Copepoda, which are meiofauna. The aims of the study were to improve understanding of regional-scale species distributions by sampling a consistent habitat that is present over a wide geographical area; and determine the importance of the Chalk as an ecological habitat by studying the extent of the habitat and the prevalence of invertebrates within the aquifer.
Invertebrate species that are obligatory inhabitants of groundwater are known as stygobites. They provide an important contribution to biodiversity (Sket 1999; Gibert and Culver 2009), as well as a range of other ecosystem services. These include their role in biogeochemical cycles and contaminant attenuation through their interaction with microbial communities (Boulton et al. 2008; Griebler et al. 2010; Korbel and Hose 2011), their potential as water-quality indicators (Danielopol 1989; Malard et al. 1996; Stein et al. 2010; Hahn 2006), and the information they may provide on past geological and climatic changes and adaptation to unusual environments (Humphreys 2009).
Several studies have demonstrated diverse stygobite communities in the hyporheic zone beneath rivers (e.g., Hancock et al. 2005; Robertson and Wood 2010); in karst caves (e.g., Culver et al. 2003; Knight 2011); in springs (e.g., Halse et al. 2002; Gibson et al. 2008); and within groundwater in carbonate, fractured and granular aquifers (e.g., Hancock and Boulton 2008; Deharveng et al. 2009; Hahn and Fuchs 2009; Galassi et al. 2009). In mainland Britain, there are eight known stygobitic macro-invertebrate species (Proudlove et al. 2003), which are all crustaceans and normally range in size from 1 to 15 mm in length. Copepoda (another crustacean group which are usually less than 1 mm in length and are therefore classified as meiofauna) and Oligochaeta (a group of worms) are also commonly present, but have not been investigated to the species level in the UK (Proudlove et al. 2003; Robertson et al. 2009). Recent genetic studies of five UK and Irish stygobitic species of the Niphargus genus have revealed that not only are they endemic lineages, but they are by far the oldest fauna present in the British Isles, having survived millions of years of climate changes in aquifers (McInerney et al. 2014).
Stygobite species diversity in the UK is low compared to other areas of the world where there may be tens of species present within a single aquifer or cave. The low diversity in the UK is thought to be due to local extinctions during glaciations (Proudlove et al. 2003; Robertson et al. 2009); however, the distribution of invertebrate stygobites is not fully known, and groundwater ecosystems represent prime examples of Linnean and Wallacean shortfalls where species diversity and distributions are inadequately characterised (Whittaker et al. 2005). Further understanding of the occurrence and distribution of groundwater invertebrates is needed to address this knowledge gap, and to enable groundwater ecosystem services to be assessed.
The first aim of the study is to use data from a single geological unit to improve understanding of large-scale species distributions. Groundwater habitats are often poorly understood, and it may be difficult to establish whether the occurrence and distribution of invertebrate species are determined by large- or small-scale processes (Malard et al. 2009). Some studies have focused on geographically large areas incorporating a range of geological habitats (e.g., Deharveng et al. 2009). Species richness has been assessed in aquifers classified as karst, porous, and fractured (e.g., Hahn and Fuchs 2009); however, a particular aquifer type may incorporate a range of geological strata that form different habitats with specific physical and chemical characteristics (Maurice and Bloomfield 2012). This study investigates boreholes in a single geological unit (the Chalk), in seven different geographical areas, which makes it possible to determine whether geographical variability in species distributions relates to regional factors such as glaciation or limited dispersal, rather than physical or chemical habitat differences that arise due to differences in geology. Previous studies have suggested that stygobite diversity and occurrence is lower in northern than southern England (Proudlove et al. 2003), although non-cavernous groundwater in northern England has not been well studied. The Chalk aquifer outcrops in extensive areas of southeast and northeast England, thereby providing an opportunity to investigate the same habitat in both the north and south of the country.
The Chalk is the most important water supply aquifer in many parts of northern Europe (Downing et al. 2005). Groundwater quality is widely monitored and regulated, and surface groundwater-dependent ecosystems are protected. However, in general, groundwater ecosystems are not considered in water management programs. Nevertheless the Chalk aquifer has been identified as a habitat for invertebrate groundwater fauna in England (Proudlove et al. 2003; Robertson et al. 2009; Sorensen et al. 2013; Johns et al. 2015), and fauna are recorded from Chalk areas in continental Europe (Deharveng et al. 2009; Martin et al. 2009; Michel et al. 2009); however, it is unclear in some of these studies which samples came from the Chalk, and questions remain about where in the aquifer invertebrates occur, and how commonly they occur. The prevalence of species in the Chalk and the importance of the Chalk as an ecological habitat have not been properly assessed. The second aim of this study is to address this by investigating how frequently stygobitic invertebrates occur in the Chalk, and considering how extensive the habitat is; for example, whether it extends to all geographical areas of Chalk outcrop; and whether it extends into areas where water tables are deep beneath the surface, or areas where the chalk is concealed by other strata.
The study aquifer: the English Chalk
The Chalk is a carbonate aquifer with small-scale surface and subsurface karst (MacDonald et al. 1998; Maurice et al. 2006). High permeability and transmissivity occurs because fractures are solutionally enlarged (Price et al. 1982; Bloomfield 1996) to form fissures (solutional voids that retain the planar geometry of the original fracture), conduits (circular shaped voids), and occasionally caves (voids large enough for humans to enter). These solutional voids form the main habitat for stygobitic invertebrates, although they may also inhabit unmodified fractures. The Chalk matrix porosity is ~ 35 % (Bloomfield et al. 1995), but permeability is very low because the pore throats are very small (Price et al. 1993). Matrix pores are < 3 µ and pore throats are < 1 µ (Hardman 1982); therefore, stygobitic macro-invertebrates are too big to live within the matrix. The Chalk is present in southern and southeast England, East Anglia and easterly areas of northern England (Fig. 1a). The aquifer is heterogeneous and boreholes may intercept varying numbers of permeable voids (Bloomfield 1996). Transmissivity is higher in northern England (Humberside and Lincolnshire) and Dorset than in other areas (Fig 1, Table 1); however, the Chalk has very high transmissivity (1,000’s m2/day) compared to many other rock types (Table 1), and provides a similar habitat for groundwater invertebrates in all areas.
In some areas, the Chalk is concealed beneath superficial deposits or younger Palaeogene strata. Where there is a substantial thickness of low permeability material overlying the Chalk and preventing direct recharge, the Chalk becomes confined, meaning that the water is under pressure. Confined Chalk has slightly lower permeability than unconfined Chalk (MacDonald and Allen 2001), and very low or absent dissolved oxygen (e.g., Smedley et al. 2003, 2004). This is because it is not well connected to recharge areas and residence times are longer. In this study there are insufficient data to determine whether the Chalk is confined. Boreholes where the Chalk is overlain by low permeability strata and are more than 1 km from outcrop or overlying permeable deposits, were classified as in “concealed” Chalk, which is likely to be confined.
Chalk groundwater chemistry is dominated by high bicarbonate, calcium and pH and there are no substantial differences between areas (Table 2). The greatest variation is between unconfined and confined chalk: confined groundwater has low or absent oxygen and nitrate, and increased sulphate, chloride and iron.
Methods
A national-scale survey of invertebrate ecology in the Chalk
Samples were obtained from 198 boreholes distributed across two areas of northern England (Humberside and Lincolnshire) and five areas of southern England (Fig. 1a). Some areas extend slightly into adjacent counties, but are named according to the county where most samples were located. The locations of samples were restricted to existing boreholes, and therefore it was not feasible to implement a randomized statistical design or to fully control factors such as the depth and diameter of each borehole. Most sampled boreholes are unpumped closed monitoring boreholes, and sites were selected on the basis of ease of access and permission to sample. Sixteen boreholes were sampled in Berkshire, East Anglia, Humberside, and Lincolnshire between 2009 and 2011, and 13 were sampled in Kent in 2011. In these areas sample distributions were determined by the availability of boreholes with the following criteria: not being pumped, only containing equipment that could be easily removed, less than 120 m deep, between 50 and 300 mm in diameter, with an uncased section open only to the Chalk. Thirty-one unpumped boreholes were sampled in Dorset in 2009 (Johns et al. 2015), and 40 unpumped and 50 pumped boreholes were sampled in Hertfordshire between 2003 and 2009.
The mean and range of borehole depths, diameters, and water levels in each area are presented in Table 3. Water levels and borehole depths were fairly similar in all areas, whilst diameters were more variable, and included some much larger diameter sites in Dorset and Hertfordshire.
Sampling was undertaken using a weighted borehole net with a 63-µ mesh and filter, and each borehole was sampled on a single occasion. Net diameters varied from 3 to 30 cm, depending on the diameter of the borehole. The net was connected to a cord and lowered to the bottom of the borehole three times to disturb sediment and then brought to the surface where sediment and fauna were collected and stored in > 96 % ethanol. This net sampling method collects an integrated sample comprising the sediment from the bottom and any invertebrates collected from other depths as the net is hauled up the borehole. Three net samples were collected at each site, except in Hertfordshire where only 1 or 2 net samples were collected; and at some Hertfordshire sites baited traps were used in addition to nets. Fifty of the Hertfordshire boreholes are actively pumped for water supply. Because of these differences in the Hertfordshire boreholes, the results are only used for descriptive purposes, and they were excluding from the statistical analyses.
In the laboratory, fauna were separated from sediment and identified using a stereoscopic microscope. A compound microscope was also used to examine further deterministic features on juvenile and damaged specimens, and for the identification of Antrobathynella stammeri and some Microniphargus leruthi specimens. Samples with substantial sediment were sieved to separate different sized particles enabling fauna to be picked out more easily. Stygobitic macro-invertebrates were identified to the species level using Gledhill et al. (1993) and Knight and Gledhill (2010). Copepoda were not identified to the species level, and therefore it is not possible to know if they are stygoxenes (surface species that accidentally entered groundwater), stygophylic (able to live in both surface and subsurface environments), or stygobitic (restricted to the subsurface).
Investigating regional-scale patterns in species distributions
The analyses are largely descriptive since the borehole locations could not be selected according to a statistical design, and the Hertfordshire boreholes have been excluded due to inconsistencies in the sampling method. The study is focused on the locations and the conditions in which the different species were observed. The variation in borehole properties such as depth, diameter, water level, length of uncased saturated section within the borehole, and distance to nearest watercourse could influence the results. It was not possible to produce robust models of the effect of each of these properties since these components of variation were confounded with spatial variation. The significance of each of the estimated parameters of such models was overly sensitive to the type of relationship that was assumed; therefore, a non-parametric method was used to explore these relationships. For each borehole property, the boreholes were divided into ten equally sized groups according to the value of the property and then the proportion of wells where each species occurred was compared for each group.
In some instances, specific species were absent from the boreholes in northern England but present in southern England. The significance of these absences was tested by fitting generalized linear models (GLM; Dobson 2001) to the data from the southern boreholes (excluding the Hertfordshire boreholes) and then using these models to predict the probability of not observing this species in any of the northern boreholes. Due to the non-random nature of the sample design these tests can only give an indication of the significance of our findings.
In each estimated GLM the occurrence of a species at borehole i is assumed to be a realization of a Bernoulli distribution and the canonical logit link function is applied so that the probability p i of occurrence is (Dobson 2001):
Where p is a length n vector containing the p i values for each borehole, X is a n × q matrix containing the value of q covariates or properties for each borehole and β is a vector of q coefficients. The models were estimated using a stepwise regression algorithm (MATLAB function stepwiseglm). This algorithm estimates a series of models by maximum likelihood. In the initial version of the model, X is a vector of ones and, hence, the p i values are identical. Then each of the borehole properties is added to the model in turn and the one which causes the biggest increase to the likelihood is selected. If a likelihood ratio test demonstrates that the increase to the likelihood is significant, then this property is added to the model and the procedure continues to test whether further properties should be added. If at any point none of the unused properties lead to a significant increase in the likelihood, then the model fitting halts. Finally, the estimated models were used to simulate 100,000 realizations of the presence/absence of the species at each of the boreholes in the north of England. If, for example, fewer than 1,000 of these realizations contained no occurrences at any of the boreholes then the observed absence in the north is statistically significant at the p = 0.01 level. The p = 0.01 level of significance was adopted for these tests rather than the more standard p = 0.05 level to account for the possibility of false rejections of the null hypothesis amongst the multiple tests (Benjamini and Hochberg 1995).
Investigating the importance of the Chalk aquifer habitat
The extent of the habitat
It was anticipated that the Chalk habitat for stygobitic invertebrates does not extend into the confined Chalk, but to investigate this, 14 boreholes were sampled from the concealed Chalk. To investigate the vertical extent of the habitat, boreholes from the unconcealed Chalk were grouped into those with water tables at < 5 m below the surface, 5–50 m below the surface, and > 50 m below the surface. For each category, the number of boreholes in which each species was found was recorded. Species found in boreholes with water tables > 50 m must have originated from deep habitats > 50 m below the surface.
Invertebrate abundance
The numbers of invertebrates collected at each sampling site provide some information on their abundance in boreholes. However, it is not clear what proportion of individuals living in the borehole are collected in a sample comprising three net hauls. If there is a decline in numbers in later net samples, it might suggest that a large proportion of invertebrates present within the borehole have been collected in the three net hauls. To investigate this, at 77 of the 198 sample sites, the three individual net hauls were collected and analysed separately enabling the numbers of stygobitic amphipods from the individual nets to be counted. Kruskal-Wallis one-way analysis of variance on ranks was used to test for differences in numbers of amphipods collected in the three net hauls. Additional sampling (not included in the main analysis) was undertaken at two boreholes in Berkshire (Calversley Farm and Brightwalton Common), where ten or more net hauls were carried out to provide further information on the number of invertebrates present in boreholes.
Faunal abundance in boreholes is not necessarily representative of abundance in the aquifer as boreholes are good habitats that tend to accumulate invertebrates (Hahn and Matzke 2005; Sorensen et al. 2013). To investigate the pervasiveness of particular species in the Chalk aquifer, the percentage of boreholes sampled which contained each species was calculated.
Results
Regional-scale invertebrate distributions in the Chalk
Seven stygobite species were identified, and Copepoda were also commonly found (Figs. 1a–h and 2, Table 4). The syncarid Antrobathynella stammeri (Jakobi 1954) was only found in Humberside, and these are the first records in this area of northeast England (Fig. 1a). The isopod Proasellus cavaticus (Leydig, 1871 sensu Henry, 1970) was found in Dorset, Hertfordshire and Kent (Fig. 1b). However, most of the stygobites found were amphipods. Crangonyx subterraneus (Bate, 1859) was present in Dorset, Berkshire and Hertfordshire (Fig. 1c). Records of Microniphargus leruthi (Schellenberg, 1934) in Dorset were the first in the Chalk and amongst the first in mainland Britain (Knight and Gledhill 2010), and it was subsequently found in Kent, East Anglia and Berkshire (Fig. 1d). Niphargus kochianus (Bate, 1859) and Niphargus fontanus (Bate, 1859) were found in all areas except Lincolnshire and Humberside (Fig. 1e,f), and the known range of N. fontanus has been extended slightly north and east into East Anglia. Niphargus aquilex (Schiödte, 1855) was recorded in all regions except Kent and Dorset (Fig. 1g), although this species is known to occur within both these areas. Copepoda were found in all areas except Lincolnshire (Fig. 1h).
Few obvious relationships between the borehole properties and the occurrence of different species were observed (Fig. 3)—for example, Fig. 3b shows how the proportion of boreholes where N. kochianus was recorded varies irregularly with the borehole depth, diameter, and water level. The variation is also irregular for Copepoda (Fig. 3h) although they are observed in a large proportion of the large diameter boreholes. The only patterns of note amongst the remaining species are that C. subterraneus is only observed in boreholes of depth less than 10.3 m and water level less than 0.75 m (Fig. 3e), and N. aquilex was not observed in shallow boreholes or boreholes with shallow water levels.
According to the GLMs of N. kochianus and N. fontanus fitted to the borehole records from southern England, the absence of these species in the boreholes from northern England was significant at the p = 0.01 level. Figure 4 shows that when the models fitted to the southern boreholes were used to simulate 100,000 realizations of the occurrences/absences in the northern boreholes, there were fewer than 1,000 realizations where the species was completely absent. However, M. leruthi, C. subterraneus and P. cavaticus were less prevalent in southern England, and their absence from the boreholes sampled in northern England proved not to be significant at this level (p-values 0.02, 0.08 and 0.26 respectively). Therefore, more boreholes would need to be sampled in northern England to determine whether these species are truly absent. In the GLMs, none of the recorded borehole properties (depth, diameter, water level, distance to nearest watercourse) proved to be a significant predictor of species presence-absence except when the model of C. subterraneus included distance to nearest watercourse and water level.
The importance of the Chalk habitat
The extent of the habitat
No invertebrate fauna were found in any of the 13 boreholes in the concealed Chalk. In the unconcealed Chalk, six of the seven macro-invertebrate species and Copepoda were found in boreholes with water levels > 50 m below the surface, demonstrating that the habitat extends to substantial depths beneath the surface (Table 5). With the exception of N. aquilex and A. Stammeri, all macro-invertebrate species and Copepoda were found in boreholes less than 21 m deep (decile 1 in Fig. 3), suggesting that they can also inhabit fairly shallow groundwater.
Invertebrate species occurrence and abundance in the unconcealed Chalk aquifer
A high proportion of boreholes in the unconcealed Chalk (67 %) contained stygobitic invertebrates. In southern England, the overall proportion was 77 %, and ranged from 68 to 92 % in the different areas (Table 4). In northern England, a smaller proportion of boreholes contained stygobites (38 %). Most boreholes contained amphipods, whilst a small number contained only the isopod P. cavaticus or the syncarid A. stammeri. In southern England, N. kochianus was by far the dominant species (Table 4), both in terms of the number of boreholes where it was present (62 % of unconcealed boreholes sampled), and the numbers of individuals collected within these boreholes, which ranged from an average of 9 in Dorset to 28 in Kent (Table 4). At sites in southern England where samples consisted of three net hauls, 779 N. kochianus were collected from 45 boreholes, equating to an average of 17 per borehole.
Other stygobitic species were present in a smaller proportion of boreholes, and in smaller numbers (Table 4). Niphargus aquilexappears present in a greater proportion of boreholes, and in higher numbers in Lincolnshire than in other areas of the UK. Copepoda were also present in a high proportion of boreholes (Table 4, Fig. 1h), and where they occurred, they were often more abundant than other groups, with tens or even hundreds of individuals collected from three net hauls within a borehole.
Borehole abundance
Of the 77 boreholes in which the three different net samples were analysed separately, 42 contained stygobitic amphipods. In these boreholes, the mean number collected declined from 6.1 in net one to 4.9 in net two to 3.0 in net three. Kruskal-Wallis one-way analysis of variance on ranks indicates that there is a significant reduction in the number of amphipods between net one and net three (p = 0.027).
Niphargids were the only invertebrates collected in the multiple net samples obtained from the Brightwalton Common and Calversley boreholes. At Brightwalton Common there were similar numbers present in 12 net samples (Fig. 5). There is no apparent decline in the numbers, suggesting that even after 12 net hauls there were more invertebrates present in the borehole. At Calversley, ten samples were collected on 15/03/10 with an apparent decline in niphargid numbers in later samples, although some individuals were still present in the final net sample (Fig. 5). Three net samples the following day (16/03/10) captured a similar number of niphargids as the first three samples collected on 15/03/10. Overall, the numbers of invertebrates collected in three net hauls are likely to represent a low estimate of the borehole abundance.
Discussion
Regional-scale patterns in stygobite species distributions
The survey of the Chalk was limited to existing boreholes and it was not possible to completely control the properties (e.g., diameter, depth, water level) of each borehole; therefore, the results are primarily descriptive. Where the significance of the absence of particular species in northern England was tested, caveats apply because of the non-statistical nature of the sample design. However, given the absence of obvious relationships between the measured borehole properties and the occurrence of each species, it is likely that the results reflect differences in the invertebrate populations and habitats. Because the unconfined Chalk aquifer provides a suitable habitat in all areas, the absence of a species within an area either indicates it is rare in Chalk boreholes, or the geographical range of the species does not extend into the area.
Two species (N. kochianus and N. fontanus) were present in a high proportion of boreholes in southern England and their absences from sampled boreholes in northern England were statistically significant. There are no previous records of these species in northern England and these findings are likely to reflect a true absence (Fig. 1e,f). Either these species have never dispersed to these areas, or they were present but did not survive the Pleistocene glaciations. The estimated Devensian glacial limit passes through the northern England Chalk sampling area, which would have been fully glaciated during the earlier, more extensive Anglian glaciation. Genetic studies have shown that the UK populations of N. kochianus and N. fontanus are ancient cryptic endemic lineages that have been in the UK at least since they separated from their nearest ancestor in continental Europe about 2.9 and 0.8 million years ago respectively (McInerney et al. 2014). The Chalk outcrop is continuous under the North Sea, and the Wash (see Fig. 1a) was only formed at the end of the Devensian glaciation, 12,000 years ago. Prior to this, there would have been a continuous Chalk habitat between East Anglia and Lincolnshire. It therefore seems possible that N. kochianus and N. fontanus might have once been present in northern England, and have been eradicated during glaciations. The creation of the Wash separating the southern and northern Chalk has made it impossible for these species to recolonize the northern England Chalk from the East Anglia Chalk because there is no continuous habitat. It is possible that they could recolonize these areas via other geologies to the west; however, low permeability mudstones, that are unlikely to provide a good habitat, occur to the west of the Chalk. Permeable superficial deposits or hyporheic zone corridors could provide dispersal corridors as suggested by Ward and Palmer (1994) for meiofauna; however, N. kochianus has not been found in UK hyporheic zones, and appears not be suited to this type of habitat (Proudlove et al. 2003). Niphargus kochianus and N. fontanus are present to the north of the Anglian glacial limit (Fig. 1f), suggesting that either they survived this glaciation in refugia, or they have recolonized this area during the 424,000 years since the end of the Anglian glaciation.
Other species distributions do extend into northern England Chalk (N. aquilex, A. stammeri), and must either have survived glaciations in refugia, or have dispersed to these areas since they were deglaciated (Proudlove et al. 2003). The genetic study by McInerney et al. (2014) showed that N. aquilex specimens from the Chalk in northern England are part of an endemic cryptic lineage that diverged from the continent about 1 million years ago; therefore, this lineage predates both the Anglian and Devensian glaciations. Niphargus aquilex is commonly found in the hyporheic zone and shallow habitats (Proudlove et al. 2003; and more recent data in the UK Hypogean Crustacea Recording Scheme database), and therefore may be able to utilise hyporheic zone dispersal corridors and superficial deposits. Other species that were not found in northern England were only found in a small proportion of Chalk boreholes in southern England (C. subterraneus, P. cavaticus, and M. leruthi). The absence of these species in the northern boreholes was not statistically significant and more boreholes would have to be sampled to demonstrate a difference between the occurrences in the north and south of England.
N. aquilex was not found in Kent or Dorset despite previous records of this species in these areas (Fig. 1g). This is likely to be because of the low numbers of N. aquilex in Chalk boreholes, compared to other habitats where it is commonly found. The absence of N. aquilex in most Chalk boreholes in southern England supports previous suggestions that this species occupies shallow habitats (Proudlove et al. 2003); however, in the six (out of 161) boreholes in unconcealed Chalk in southern England where it was present, water levels ranged from 12 to 77 m below the ground surface, indicating that the species can also occur in deep groundwater; and as shown in Fig. 3a, N. aquilex was not found in shallow boreholes in this study. It is unclear why N. aquilex appears more common in the northern England unconcealed Chalk, where it was present in seven out of 24 boreholes which had a mean water level 48.4 m below the surface.
The importance of the Chalk as an ecological habitat
There were no invertebrates captured in any of the 13 boreholes that are classified as concealed and are likely to be in confined Chalk. Although this is only a small number of sites, it is quite likely that stygobitic invertebrates are generally absent from the confined Chalk, because dissolved oxygen is absent or very low. This is as a consequence of little water circulation and long water residence times, which may be up to thousands of years in deeply confined areas (Smith et al. 1976). Although stygobites have been found in a wide range of dissolved oxygen conditions (Boulton et al. 1992), and they have been shown to be more resistant to anoxia than surface water invertebrates, they do not appear to be able to survive in such conditions indefinitely (Malard and Hervant 1999), and studies have demonstrated that stygobitic species require well-oxygenated waters (e.g., Dole-Olivier et al. 2009).
This study shows that stygobitic invertebrates inhabit both shallow and deep groundwater environments in the unconcealed Chalk aquifer. Hydrogeological investigations have demonstrated water circulation extending to 50 m below the water table (Price 1987; MacDonald and Allen 2001; Schurch and Buckely 2002) with oxygenated waters (Edmunds et al. 2003); and solutional fissures have been observed up to 80 m (Maurice et al. 2012). Targeted sampling of individual fissures using inflatable packers to isolate them has revealed that stygobitic invertebrates are present in fissures up to 98 m below the surface in the Chalk aquifer (Sorensen et al. 2013). The unconcealed Chalk therefore provides a vertically as well as laterally extensive habitat for invertebrates.
Estimating invertebrate abundance in aquifers is difficult because invertebrates tend to be concentrated within boreholes (Hahn and Matzke 2005; Eberhard et al. 2009; Sorensen et al. 2013). It is impossible to relate the numbers of invertebrates collected from borehole net samples to the number present in the aquifer because it is uncertain how long they have been in the borehole, and how many different fissures contributed invertebrates. Large numbers collected in net hauls may reflect high numbers in the aquifer, or may occur because individuals have been in the borehole for a long time and accumulated or reproduced. The proportion of boreholes in which a species is found is perhaps a better indication of the species prevalence in the aquifer. Given that individual boreholes are just point samples in a potentially extensive habitat, and that previous studies (in other geologies) have suggested that multiple sampling occasions are often required to detect species in boreholes (Allford et al. 2008; Eberhard et al. 2009; Hancock and Boulton 2009), it is remarkable that 67 % of our borehole samples detected stygobitic invertebrates on just a single sampling occasion. It is clear that the Chalk represents an important and widespread habitat for groundwater adapted invertebrates in England, and is likely to do so throughout Europe, where similar hydrogeological conditions exist (Downing et al. 2005), and fauna have been previously recorded (Deharveng et al. 2009; Martin et al. 2009; Michel et al. 2009).
Niphargus kochianus is the most abundant stygobitic invertebrate species in Chalk boreholes with between 9 and 28 individuals captured per borehole in southern England (Table 4, Fig. 1e). Where present, Copepoda occurred in even greater numbers (Table 4). Niphargus kochianus and Copepoda appear well suited to the Chalk borehole environment, and high numbers may reflect reproduction within the borehole. However, they are also found in a high proportion of boreholes, indicating that they are likely to be common within the aquifer. It has been suggested that stygobitic invertebrates may be useful indicators of groundwater quality (Stein et al. 2010); however, one difficulty is that many species are sparsely distributed within aquifers. Niphargus kochianus is unusual because it is widespread in Chalk boreholes in southern England, and might therefore be a good water quality indicator, although studies would be needed to determine its ecological optima and tolerance ranges with respect to specific physical and chemical variables.
Other stygobitic species (N. aquilex, N. fontanus, C. subterraneus, P. cavaticus, A. stammeri, M. leruthi) occurred in much lower numbers. There were generally only 1–3 individuals collected from boreholes where they were present. Despite this, N. fontanus occurred in a reasonably high proportion of boreholes in southern England, suggesting that it may be fairly widespread in the aquifer. Crangonyx subterraneus, P. cavaticus and A. stammeri were present in a small proportion of boreholes and appear to be relatively uncommon in the Chalk. Although these species can be locally abundant in other geologies, they occur relatively rarely (Fig. 1a–c; see also Johns et al. 2015). Niphargus aquilex occurred in a small proportion of Chalk boreholes (Table 4), but there are many records from shallower sample sites (the hyporheic zone, springs and shallow wells; Fig. 1g), suggesting that presence may be lower in Chalk groundwater than in other habitats.
The English Chalk crops out over an area of more than 20,000 km2 and just the top 20 metres of the saturated zone contain 4,000 million m3 of water (British Geological Survey and UK Groundwater Forum, 2014). The aquifer and habitat are vertically much more extensive, and in areas where the Chalk has a thin cover, groundwater remains unconfined and well oxygenated, so it is likely that the habitat may also extend laterally into areas beyond the Chalk outcrop. This study found thousands of macro-invertebrates and thousands of Copepoda in only 198 boreholes. This represents a tiny fraction of the aquifer and therefore it is likely that there are millions to billions of macro-invertebrates and Copepoda present within the Chalk, which together with the microbial community, are likely to affect biogeochemical cycles in groundwater.
Conclusions
Investigating a single geological unit is useful to improve understanding of stygobitic invertebrates to guide their conservation and assess the services provided by subsurface ecosystems. Sampling boreholes in the same geological unit over a wide geographical area enabled patterns in species distributions to be more clearly understood than if multiple geologies or different environments had been sampled. This was the first extensive sampling of non-cavernous groundwater in northern England, and there were sufficient samples to establish that two stygobitic species present in southern England are very likely to be absent from northern England. However, the study also shows that three other species occur sufficiently rarely in southern England, that more sampling would be required to determine whether they are truly absent from northern England. The study includes some of the first records of M. leruthi, and revealed that this species is distributed throughout the Chalk of southern England.
Stygobitic invertebrates appear to be absent from the concealed Chalk where dissolved oxygen is low, but are remarkably common in boreholes in the unconcealed Chalk. They were common in boreholes with deep water tables, suggesting that the entire unconfined Chalk water supply aquifer contains an ecosystem comprising invertebrate communities that interact with microbial communities, and may influence biogeochemical cycles. The amphipod N. kochianus is very prevalent in southern England. Copepoda are also common, and occur in large numbers, but the controls on their distribution, and their role in ecosystem functioning remains unknown.
Overall, our study demonstrates that the English Chalk harbors an important ecosystem. The invertebrate species present are important to science because they are unusual organisms that are adapted to live in the subsurface environment where resources are sparse. Genetic studies (McInerney et al. 2014) show that the three Niphargus species found in the Chalk represent lineages that separated from their nearest relatives in continental Europe between 0.6 and 5.6 million years ago, and are therefore ancient species that have survived extreme climate and geological changes. As specialist organisms with their own habitat requirements they represent a unique component of biodiversity which offer opportunities for new scientific discoveries.
